Schneider Electric Molded Case Circuit Breaker ComPact Compact NSXm 3-Pole 32A 70kA Breaking Capacity 690V AC LV426502

Schneider Electric LV426502 Molded Case Circuit Breaker is a high-performance electrical protection device from the ComPact Compact NSXm series. With a 3-pole configuration and a current rating of 32 amperes, it is engineered to provide reliable circuit protection against overcurrents and faults in industrial, commercial, and infrastructure environments.

This circuit breaker features a breaking capacity of 70 kiloamperes at 380/415 volts AC, ensuring robust interruption capability in case of short circuits or overloads. It supports a rated AC voltage of 690 volts, making it versatile for various electrical installations.

The unit is equipped with a thermal magnetic tripping mechanism for balanced protection and a Type D tripping characteristic suitable for motor circuits and inductive loads. The toggle switch reset actuator facilitates quick manual operation for resetting after trips.

Mounting is of the clip-on type, allowing easy installation into electrical panels with secure screw terminal connections. The compact dimensions of 137 mm in width and height, and 80 mm in depth, enable efficient panel space utilization.

Certified under CE, CCC, EAC, EN, IEC, and RoHS standards, the breaker assures compliance with stringent international safety and environmental regulations. The inclusion of EverLink lugs further enhances terminal connection reliability.

This Molded Case Circuit Breaker is ideal for use in industrial automation, electrical distribution boards, HVAC systems, manufacturing plants, and other applications requiring dependable circuit protection.

This Molded Case Circuit Breaker is designed for reliable protection of electrical circuits in industrial and commercial applications. It supports a rated AC voltage of up to 690 volts with a thermal magnetic tripping mechanism.

The device provides robust protection and switching via a toggle switch reset actuator and Type D tripping characteristics. Mount type is clip-on with screw terminals ensuring secure and easy installation. Dimensions include a width and height of 137 mm and depth of 80 mm for compact panel integration.

Certifications include CE, CCC, EAC, EN, IEC, and RoHS compliance, ensuring international standards adherence. Suitable for applications in electrical distribution, automation, and industrial control panels. Incorporates EverLink lugs for enhanced electrical connection reliability.
