ABB Tmax XT Molded Case Circuit Breaker 4-Pole 63A 50 kA Breaking Capacity Fixed 1SDA068258R1 XT3N 250 TMG 63A FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Tmax XT Molded Case Circuit Breaker 4-Pole 63A 50 kA Breaking Capacity Fixed 1SDA068258R1 XT3N 250 TMG 63A FF



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	150mm
Model	1SDA068258R1 XT3N 250 TMG 63A FF
Depth	70mm
Width	140mm
Mount Type	Fixed
Current Rating	63A
Series	Tmax XT
Terminal type	Fixed
Breaking Capacity	50kA
Number of Poles	4
Standards/Approvals	CE, IEC, RoHS
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Better World Claim	Designed for Disassembly
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Lever
Rated current (In)	63 A In
Rated frequency (f)	50/60 Hz
Rated voltage (Ur)	690 V
Rated impulse withstand voltage (Uimp)	8 kV

Key Features

Thermal Magnetic tripping mechanism for reliable circuit protection.
Rated AC voltage of 690V and DC voltage of 500V suitable for various industrial applications.
Compact dimensions of 150mm height, 140mm width, and 70mm depth.
Designed for fixed mounting with front terminal type.
Compliant with CE, IEC, and RoHS standards ensuring product quality and safety.
Equipped with a lever type reset actuator for ease of use.
Offers a rated uninterrupted current of 160A for enhanced performance.
Manufactured in Italy with sustainability-focused design features.

Product Description

ABB 1SDA068258R1 XT3N 250 TMG 63A FF Molded Case Circuit Breaker from the Tmax XT series is engineered for dependable electrical circuit protection in industrial and commercial environments. This 4-pole fixed type breaker has a rated current of 63 amperes and can safely interrupt fault currents up to 50 kiloamperes, making it suitable for medium to high power applications.

Constructed with a thermal magnetic (TMG) tripping mechanism, it offers enhanced protection against overloads and short circuits. The device supports a rated AC voltage of 690 volts and a rated DC voltage of 500 volts, providing versatile use across AC and DC circuits. Its compact build with 150 mm height, 140 mm width, and 70 mm depth facilitates easy installation in panels with limited space.

The front terminal design and fixed mount type assure secure and stable connectivity while the lever reset actuator ensures quick reactivation post-tripping. Compliance with CE, IEC, and RoHS standards guarantees adherence to international quality and environmental regulations. As a Better World product, it is designed for disassembly to promote sustainability and efficient recycling.

This circuit breaker is ideal for various industrial sectors including manufacturing, electrical distribution, automation, and HVAC systems. Its robust construction and precise tripping characteristics help improve system reliability and safety.

Thermal Magnetic tripping mechanism for circuit protection. Rated current of 63A and breaking capacity of 50 kA for medium to high power circuits. Rated AC voltage 690V and DC voltage 500V for versatile usage. Compact dimensions: 150mm height, 140mm width, 70mm depth.
