ABB Tmax XT Molded Case Circuit Breaker 3-Pole 160A Breaking Capacity 150 kA Fixed Mount 690V 1SDA068292R1 XT4L 160 BLOC FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Tmax XT Molded Case Circuit Breaker 3-Pole 160A Breaking Capacity 150 kA Fixed Mount 690V 1SDA068292R1 XT4L 160 BLOC FF



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	160mm
Model	1SDA068292R1 XT4L 160 BLOC FF
Depth	82.5mm
Width	105mm
Mount Type	Fixed
Current Rating	160A
Series	1SDA06
Terminal type	Fixed
Breaking Capacity	150kA
Number of Poles	3
Standards/Approvals	RoHS, IEC, CE
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Better World Claim	Designed for Disassembly
Reset Actuator Type	Lever
Short circuit performance level	L

Key Features

Designed for fixed mounting to ensure secure installation.
Rated AC voltage of 690V and DC voltage of 500V for versatile applications.
Complies with RoHS, IEC, and CE standards ensuring high safety and reliability.
Equipped with a lever reset actuator for convenient operation.
Features front fixed terminals for stable wiring connections.
Offers electrical durability rating of 120 cycles per hour with 1000 V rated insulation voltage.
Built as part of the Tmax XT range and 1SDA06 series for quality assurance.
Manufactured in Italy, emphasizing premium build and quality control.

Product Description

The ABB 1SDA068292R1 XT4L 160 BLOC FF Molded Case Circuit Breaker is a high-performance electrical protection device designed for industrial, commercial, and utility applications. It is part of the Tmax XT range and the 1SDA06 series, ensuring robust quality and proven reliability.

This 3-pole breaker is rated for a current of 160 amps and provides an exceptional breaking capacity of 150 kiloamperes, making it suitable for demanding electrical circuits requiring high fault interruption capability. The fixed mount design and front fixed terminal configuration provide secure installation and wiring stability.

With a rated AC voltage of 690V and rated DC voltage of 500V, this circuit breaker is versatile for use in various power systems. It complies with international standards including RoHS, IEC, and CE, ensuring environmental compliance and safety standards adherence.

The compact physical dimensions (height 160 mm, width 105 mm, depth 82.5 mm) allow for efficient panel space utilization. Its lever-type reset actuator offers easy manual control for resetting after fault clearing events.

The device boasts an electrical durability of 120 cycles per hour with 1000 V rated insulation voltage, enhancing operational stability under frequent switching conditions. The short circuit performance level is rated as ‘L’, signifying a reliable classification within the range.

Manufactured in Italy, this breaker carries the assurance of premium European craftsmanship. The design also supports environmentally responsible practices with a better world claim for designed disassembly.

Designed for fixed mounting to ensure secure installation. Rated for 160 A uninterrupted current and 150 kA breaking capacity. Complies with RoHS, IEC, and CE standards. Compact size with 160 mm height, 105 mm width, and 82.5 mm depth.

Lever reset actuator for easy manual control. Front fixed terminals for secure wiring connections. Electrical durability of 120 cycles per hour with 1000 V insulation voltage. Manufactured in Italy with superior quality standards.

Short circuit performance level: L.

This ABB Molded Case Circuit Breaker is ideal for use in electrical distribution panels, manufacturing, industrial automation, and commercial electrical setups requiring reliable circuit protection. Explore the wider range of MCCBs and circuit protection products from ABB and related brands on EnvMart for comprehensive electrical safety solutions.
