ABB Tmax XT Molded Case Circuit Breaker 4-Pole 160A 690V AC Breaking Capacity 200kA 1SDA068027R1 XT2V 160 Ekip LSIG 160A FF
Specifications
| Country of Origin | Italy |
|---|---|
| Range | Tmax XT |
| Brand | ABB |
| Height | 130mm |
| Model | 1SDA068027R1 XT2V 160 Ekip LSIG 160A FF |
| Depth | 82.5mm |
| Width | 120mm |
| Mount Type | Fixed |
| Current Rating | 160A |
| Series | 1SDA06 |
| Terminal type | Fixed |
| Breaking Capacity | 200kA |
| Number of Poles | 4 |
| Standards/Approvals | CE, RoHS, IEC |
| Rated AC Voltage | 690V ac |
| Better World Claim | Designed for Disassembly |
| Tripping Mechanism | Solid State |
| Reset Actuator Type | Lever |
| Rated current (In) | 160 A In |
| Rated frequency (f) | 50/60 Hz |
| Rated voltage (Ur) | 690 V |
| Rated impulse withstand voltage (Uimp) | 8 kV |
Key Features
- Designed with a solid state tripping mechanism for reliable protection.
- Features a fixed mount and terminal type for secure installation.
- Compact dimensions of 130mm height, 120mm width, and 82.5mm depth.
- Includes a lever-type reset actuator for easy operation.
- Conforms to CE, RoHS, and IEC standards ensuring safety compliance.
- Rated impulse withstand voltage of 8 kV for electrical durability.
- Operates effectively at frequency range of 50/60 Hz.
- Manufactured in Italy with a Better World Claim for designed disassembly.
Product Description
ABB presents the 1SDA068027R1 XT2V 160 Ekip LSIG 160A FF Molded Case Circuit Breaker from the Tmax XT range, designed to offer robust electrical protection in demanding industrial and commercial environments. This fixed 4-pole breaker supports a current rating of 160A with a rated AC voltage of 690V and an outstanding breaking capacity of 200kA, ensuring superior circuit interruption capability.
The device incorporates a solid state tripping mechanism within the Ekip LSIG system for accurate and reliable fault detection and disconnection. It is equipped with front fixed terminals and a convenient lever reset actuator that simplifies manual resetting after tripping events.
With compact dimensions of 130mm in height, 120mm in width, and 82.5mm in depth, this breaker is suitable for integration into various electrical distribution panels where space efficiency is critical. Rated to withstand impulse voltages up to 8 kV, it provides exceptional durability against voltage spikes.
Compliant with international standards including CE, RoHS, and IEC, this ABB breaker also carries a Better World designation for designed disassembly, illustrating a commitment to sustainability. The unit operates effectively across electrical frequencies of 50/60 Hz, making it versatile for global applications.
Solid state tripping mechanism for reliable fault protection. Fixed mounting and terminal types for stable installation. Lever reset actuator enabling easy manual reset. Compact size facilitating installation in limited spaces.
High breaking capacity of 200kA suitable for heavy-duty circuits. Compliance with CE, RoHS, and IEC standards ensuring safety. Designed with sustainability in mind for easy disassembly. Manufactured in Italy delivering quality assurance.
This ABB Tmax XT breaker is ideal for industrial, commercial, and electrical automation systems requiring dependable circuit interruption and personnel safety. Browse more Molded Case Circuit Breakers from ABB and related electrical protection devices on EnvMart for enhanced electrical reliability and efficiency.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The breaker has a breaking capacity of 200kA, making it suitable for heavy-duty circuits.
It is rated for a current of 160A and operates at a voltage of 690V AC.
This model features a solid state tripping mechanism for accurate and reliable fault detection.
The dimensions are 130mm in height, 120mm in width, and 82.5mm in depth.
It operates effectively at a frequency range of 50/60 Hz.
It includes a lever-type reset actuator that simplifies manual resetting after tripping events.
Yes, it conforms to CE, RoHS, and IEC standards ensuring safety compliance.
It is manufactured in Italy, ensuring quality assurance.
The rated impulse withstand voltage is 8 kV, providing durability against voltage spikes.
This breaker features a fixed mount type for secure installation.
This model is a 4-pole circuit breaker.
It carries a Better World Claim for being designed for disassembly, highlighting a commitment to sustainability.
