ABB Tmax XT Molded Case Circuit Breaker 4-Pole 100A 200kA Breaking Capacity Fixed 1SDA068019R1 XT2V 160 Ekip LSI 100A FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Tmax XT Molded Case Circuit Breaker 4-Pole 100A 200kA Breaking Capacity Fixed 1SDA068019R1 XT2V 160 Ekip LSI 100A FF



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	130mm
Model	1SDA068019R1 XT2V 160 Ekip LSI 100A FF
Depth	82.5mm
Width	120mm
Mount Type	Fixed
Current Rating	100A
Series	1SDA06
Terminal type	Fixed
Breaking Capacity	200kA
Number of Poles	4
Standards/Approvals	RoHS, IEC, CE
Rated AC Voltage	690V ac
Better World Claim	Designed for Disassembly
Tripping Mechanism	Solid State
Reset Actuator Type	Lever
Rated current (In)	100 A In
Rated frequency (f)	50/60 Hz
Rated voltage (Ur)	690 V
Rated impulse withstand voltage (Uimp)	8 kV

Key Features

The breaker features a four-pole configuration suitable for multiphase circuits.
It has a current rating of 100 amps to handle substantial electrical loads.
Rated AC voltage is 690 volts, compatible with high voltage industrial systems.
Breaking capacity of 200 kiloamperes ensures reliable interruption during fault conditions.
The device includes a solid state tripping mechanism with Ekip LSI technology for precise protection.
Its fixed terminal type and fixed mounting support secure installation in switchgear.
Complies with RoHS, IEC, and CE standards ensuring safety and quality.
Compact dimensions with height 130 mm, width 120 mm, and depth 82.5 mm optimize panel space.

Product Description

ABB 1SDA068019R1 XT2V 160 Ekip LSI 100A FF Molded Case Circuit Breaker (MCCB) is a robust 4-pole electrical protection device designed for industrial, commercial, and manufacturing electrical distribution systems. It handles a rated current of 100 amps and supports an AC voltage of 690 volts. The breaker is engineered with a breaking capacity of 200 kiloamperes, allowing it to safely interrupt high fault currents, protecting wiring and equipment from damage.

This MCCB features a fixed mount design with front fixed terminals, ensuring stable and secure installation within switchboards. Its tripping mechanism employs advanced solid state technology using Ekip LSI, which enables precise protection settings and reliable operation. The reset actuator is a lever type, allowing easy manual reset after a trip event.

The product dimensions are compact, measuring 130 mm in height, 120 mm in width, and 82.5 mm in depth, making it suitable for installations with space constraints. The device meets important compliance standards including RoHS, IEC, and CE, ensuring adherence to international safety and environmental regulations.

Originating from Italy, this ABB MCCB is designed with sustainability in mind, certified as a Better World Product and meeting design-for-disassembly criteria supporting ecological considerations.

The breaker’s 4-pole configuration supports multiphase circuits for enhanced versatility. The rated frequency is 50/60 Hz, suitable for global power systems. The rated impulse withstand voltage is 8 kV, protecting against transient voltage spikes.

This MCCB is ideal for use in industrial automation, electrical distribution, manufacturing plants, HVAC systems, and commercial power panels. Ensures safety through reliable interruption of overloads and short circuits within rated specifications.
