ABB Tmax XT Molded Case Circuit Breaker 3-Pole 10A, Breaking Capacity 200 kA, Fixed 1SDA067971R1 XT2V 160 Ekip LS/I 10A FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Tmax XT Molded Case Circuit Breaker 3-Pole 10A, Breaking Capacity 200 kA, Fixed 1SDA067971R1 XT2V 160 Ekip LS/I 10A FF



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	130mm
Model	1SDA067971R1 XT2V 160 Ekip LS/I 10A FF
Depth	82.5mm
Width	90mm
Mount Type	Fixed
Current Rating	10A
Series	1SDA06
Terminal type	Fixed
Breaking Capacity	200kA
Number of Poles	3
Standards/Approvals	CE, IEC, RoHS
Rated AC Voltage	690V ac
Better World Claim	Designed for Disassembly
Tripping Mechanism	Solid State
Reset Actuator Type	Lever
Rated current (In)	10 A In
Rated frequency (f)	50/60 Hz
Rated voltage (Ur)	690 V
Rated impulse withstand voltage (Uimp)	8 kV

Key Features

Rated AC voltage of 690V ensures compatibility with high voltage applications.
Solid state tripping mechanism delivers precise and stable circuit protection.
Equipped with a lever reset actuator for easy manual operation.
Complies with CE, IEC, and RoHS standards for safety and environmental compliance.
Designed for disassembly supporting sustainable maintenance and recycling.
Features fixed terminals ensuring a secure connection.
Rated impulse withstand voltage of 8 kV safeguards against voltage spikes.
Applicable frequency range of 50/60 Hz for versatile use.

Product Description

ABB 1SDA067971R1 XT2V 160 Ekip LS/I 10A FF Molded Case Circuit Breaker is engineered for reliable protection of electrical circuits in industrial, commercial, and manufacturing environments. This 3-pole breaker is designed to handle a rated current of 10 amperes with a robust breaking capacity of 200 kA, suitable for high demanding power distribution systems.

Featuring a Tmax XT range and 1SDA06 series designation, it includes a solid state tripping mechanism that maintains precise, rapid response to overloads and short circuits. The fixed mounting and terminal types provide secure installation and connection integrity within electrical panels.

The breaker supports a rated AC voltage up to 690 volts and withstands impulse voltages up to 8 kV, ensuring operational safety even under transient conditions. It operates efficiently at 50/60 Hz frequency ranges, making it compliant with global AC power standards.

Its compact size (90 mm width, 130 mm height, and 82.5 mm depth) facilitates space-saving panel configurations. The front lever actuator allows for easy manual reset after tripping events.

Certified by CE, IEC, and RoHS standards, this Better World product emphasizes sustainability with its design for disassembly, promoting recycling and environmental responsibility.

Rated current: 10 A at 690 V AC. Breaking capacity: 200 kA for high fault tolerance. Three poles for balanced multi-phase protection. Solid state release with Ekip LSI for reliable performance. Fixed mount and terminals for secure installation.

Compact dimensions for efficient use of panel space. Compliant with international safety standards CE, IEC, RoHS. Designed with sustainability and disassembly in mind. Operates with rated frequency 50/60 Hz.

This Molded Case Circuit Breaker is ideally suited for electrical distribution, protection of industrial machinery, HVAC systems, manufacturing plants, and commercial electrical infrastructure. It offers stable, high-capacity protection where electrical reliability is paramount.
