Hongfa Europe GMBH PCB Signal Relay 12V DC Coil 2A DPDT HFD2/012-S-D
Specifications
| Country of Origin | China |
|---|---|
| Brand | Hongfa Europe GMBH |
| Height | 10.6mm |
| Length | 20.2mm |
| Model | HFD2/012-S-D |
| Width | 10.2mm |
| Mount Type | PCB |
| Contact Material | Gold Plated |
| Series | HFD2 |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 2A |
| Terminal type | PCB Terminal |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 960Ω |
| Coil Voltage | 12V dc |
| Switching DC Voltage | 220V dc |
| Switching AC Voltage | 250V ac |
| Coil Power | 150mW |
| Switching Power | 90W |
| Outline Dimensions | (20.2 x 10.2 x 10.6) mm |
| High switching capacity | 125VA / 90W |
| High sensitive | 150mW |
Key Features
- The relay features a 12V DC coil voltage for efficient operation.
- Contact configuration is double-pole double-throw (DPDT) ensuring versatile circuit control.
- Mount type is PCB allowing easy integration on printed circuit boards.
- Switching current rating is 2A, with switching AC voltage up to 250V AC and DC voltage up to 220V DC.
- The product operates reliably within a temperature range of -40°C to 85°C.
- Gold-plated contacts ensure enhanced conductivity and durability.
- Coil resistance is 960Ω with a coil power consumption of 150mW, providing energy-efficient switching.
- Contact resistance is low at 100mΩ, indicating minimal electrical loss.
Product Description
Hongfa Europe GMBH HFD2/012-S-D PCB Signal Relay is a specialized electronic component designed for reliable signal switching with a coil voltage of 12V DC and a double-pole double-throw (DPDT) contact configuration. It supports a switching current of 2A and can handle switching voltages of up to 250V AC and 220V DC. This relay is essential for industrial, laboratory, and automation control applications requiring precise signal conditioning.
The relay's compact dimensions (20.2 x 10.2 x 10.6 mm) and PCB mount type make it suitable for space-constrained circuit board designs. With gold-plated contacts, it ensures excellent conductivity and long-lasting performance. Its coil resistance of 960Ω and coil power consumption of only 150mW reflect energy efficiency in operation.
Designed to operate under a temperature range from -40°C to 85°C, this relay is suitable for harsh environments. It is epoxy sealed for automatic wave soldering and cleaning processes, increasing reliability and ease of manufacturing.
The relay provides high sensitivity with 150mW coil power. It offers high switching capacity up to 125VA / 90W for demanding electrical loads. Bifurcated contacts improve contact reliability and signal integrity. Epoxy sealing protects the relay internals against environmental contaminants.
Its design includes the possibility of single side stable and latching types for varied applications. Environmental compliance with RoHS standards ensures reduced hazardous material use.
This product is primarily manufactured in China and is well suited for industrial automation, control systems, HVAC, manufacturing electronics, and signal conditioning in electrical circuits. Its precision and durability make it an ideal choice for professionals requiring dependable relay components.
Explore more Signal Relay solutions and related electronics at EnvMart for your industrial and automation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay operates with a coil voltage of 12V DC, allowing for efficient operation in various applications.
This model features a double-pole double-throw (DPDT) contact configuration, enabling versatile circuit control.
It has a maximum switching current rating of 2A, suitable for controlling various electrical loads.
The relay can handle switching voltages up to 250V AC and 220V DC, making it versatile for different applications.
The relay has compact dimensions of 20.2 mm in length, 10.2 mm in width, and 10.6 mm in height, making it suitable for space-constrained designs.
The coil resistance is 960Ω, which contributes to its energy-efficient operation with a coil power consumption of 150mW.
It operates reliably within a temperature range of -40°C to 85°C, suitable for harsh environments.
This model is designed for PCB mounting, facilitating easy integration into printed circuit boards.
The contact resistance is low at 100mΩ, indicating minimal electrical loss during operation.
It complies with RoHS standards, ensuring reduced hazardous material use in its construction.
The relay supports a high switching capacity of up to 125VA / 90W, suitable for demanding electrical loads.
The contacts are made of gold-plated material, enhancing conductivity and durability.
