Hongfa Europe GMBH PCB Signal Relay 24V DC Coil 2A DPDT HFD4/24-L
Specifications
| Country of Origin | China |
|---|---|
| Brand | Hongfa Europe GMBH |
| Height | 5.4mm |
| Length | 10mm |
| Model | HFD4/24-L |
| Width | 6.5mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | HFD4 |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 2A |
| Terminal type | PCB Terminal |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 2880Ω |
| Coil Voltage | 24V dc |
| Switching DC Voltage | 220V dc |
| Switching AC Voltage | 250V ac |
| Coil Power | 200mW |
| Switching Power | 60W |
Key Features
- This relay operates at coil voltage of 24V DC with a coil resistance of 2880Ω.
- Designed for PCB mounting with PCB terminals for easy installation.
- Contacts are made of silver alloy ensuring high electrical endurance and low contact resistance of 100mΩ.
- Suitable for switching voltages up to 250V AC and 220V DC with a switching power of 60W.
- Operates reliably in a temperature range from -40°C to 85°C.
- Features low coil power consumption of 200mW, ideal for energy-efficient applications.
- The relay offers high mechanical endurance with a life expectancy of 100 million cycles.
- It provides high isolation voltage of 1.6KV between coil and contacts for safety.
Product Description
Hongfa Europe GMBH HFD4/24-L is a high-performance PCB signal relay designed for industrial and laboratory automation applications. It features a non-latching DPDT contact configuration actuated by a 24V DC coil, capable of switching up to 2A of AC/DC current safely. The relay's silver alloy contacts provide excellent electrical endurance and minimal contact resistance, ensuring reliable signal switching.
Engineered for compact PCB mounting, this relay includes PCB terminals and offers a compact footprint with a length of 10mm, width of 6.5mm, and height of 5.4mm. Its coil power consumption is low at 200mW, contributing to energy-efficient designs.
The HFD4/24-L relay performs reliably within a temperature range from -40°C to 85°C and achieves an isolation voltage of 1.6KV between coil and contacts, making it suitable for harsh industrial environments. It withstands surge voltages up to 2500VAC and is resistant to vibration and abrasion, enhancing durability and longevity.
Typical applications include control devices in automotive industry, household appliances, industrial machinery, and telecommunications where precise and reliable signal switching is essential.
This RoHS compliant relay is manufactured in China and conforms to environmental standards for sustainable use in various electronic and electrical systems. This relay operates at coil voltage of 24V DC with a coil resistance of 2880Ω.
Designed for PCB mounting with PCB terminals for easy installation. Contacts are made of silver alloy ensuring high electrical endurance and low contact resistance of 100mΩ. Suitable for switching voltages up to 250V AC and 220V DC with a switching power of 60W.
Operates reliably in a temperature range from -40°C to 85°C. Features low coil power consumption of 200mW, ideal for energy-efficient applications. The relay offers high mechanical endurance with a life expectancy of 100 million cycles.
It provides high isolation voltage of 1.6KV between coil and contacts for safety. Compact dimensions: 10mm length, 6.5mm width, and 5.4mm height save PCB space. Environmental friendly RoHS certified product manufactured in China.
Explore more Signal Relay products on EnvMart to find compatible solutions for your industrial and automation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The coil voltage of this relay is 24V DC.
It can safely switch currents up to 2A.
This relay has a length of 10mm, a width of 6.5mm, and a height of 5.4mm.
It is designed for PCB mounting and includes PCB terminals for easy installation.
The relay features a DPDT (Double Pole Double Throw) contact configuration.
The contact resistance is 100mΩ, ensuring low resistance for efficient operation.
It operates reliably within a temperature range from -40°C to 85°C.
The coil power consumption is low at 200mW, making it suitable for energy-efficient applications.
It is suitable for switching voltages up to 250V AC and 220V DC.
The relay has a mechanical endurance with a life expectancy of 100 million cycles.
Yes, the HFD4/24-L relay is RoHS compliant, adhering to environmental standards.
The contacts are made of silver alloy, providing high electrical endurance.
