Hongfa Europe GMBH PCB Power Relay, 24V dc Coil, 10A Switching Current, SPST HF46F-G/24-HS1F(610)
Specifications
| Country of Origin | China |
|---|---|
| Brand | Hongfa Europe GMBH |
| Height | 15.3mm |
| Length | 20.5mm |
| Model | HF46F-G/24-HS1F(610) |
| Width | 7mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | HF46F-G |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | PCB Pin |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 2.9kΩ |
| Coil Voltage | 24V dc |
| Switching DC Voltage | 30V dc |
| Switching AC Voltage | 277V |
| Coil Power | 200mW |
Key Features
- The relay features a low mounting height of 15.3mm, ideal for compact PCB installations.
- It provides switching AC voltage up to 277V and DC voltage of 30V.
- Coil power consumption is low at 200mW, enhancing energy efficiency.
- Durable silver alloy contacts ensure long-lasting performance and low contact resistance.
- Operational temperature range spans from -40°C to 85°C for versatile applications.
- The relay is plastic sealed, providing environmental protection and RoHS compliance.
- Isolation between coil and contacts is rated at 10KV, ensuring electrical safety.
- Designed for usage in automotive engines, household appliances, industrial machinery, medical and telecommunication equipment.
Product Description
Hongfa Europe GMBH HF46F-G/24-HS1F(610) is a reliable PCB Power Relay featuring a 24V dc coil and capable of switching currents up to 10A with an SPST contact configuration. This subminiature intermediate power relay provides a low mounting height of 15.3mm, making it suitable for compact PCB layouts requiring efficient electrical switching.
With switching AC voltage capability of 277V and DC voltage up to 30V, the relay supports a variety of electrical applications. The coil power consumption is energy efficient at just 200mW, and the coil resistance is 2.9kΩ. The relay construction includes plastic sealing and silver alloy contacts, which ensure high durability and low contact resistance of 100mΩ.
Operating reliably within a temperature range from -40°C to 85°C and featuring a coil to contact isolation voltage of 10KV, this relay is designed for robust electrical performance and safety compliance, including RoHS certification. It is ideal for industrial, automotive, household appliance, medical, and telecommunications applications, delivering effective relay switching in demanding environments.
The relay offers a compact PCB pin mount with low height and durable construction. Silver alloy contacts deliver reliable switching and longevity. Wide service temperature range ensures stable performance. High coil isolation voltage enhances electrical safety.
Low coil power consumption reduces overall system energy use. Plastic sealed design protects internal elements. Suitable for automotive engines, industrial machinery, and telecommunication equipment. Explore this powerful relay as part of EnvMart’s extensive catalog of industrial electronics and electrical components for your specialized application needs.
Explore more products in our Power Relays category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay has a switching current capacity of up to 10A.
This model operates with a coil voltage of 24V DC.
It features a Single Pole Single Throw (SPST) contact configuration.
The relay has a height of 15.3mm, a length of 20.5mm, and a width of 7mm.
It can switch AC voltage up to 277V and DC voltage up to 30V.
The coil power consumption is 200mW, which enhances energy efficiency.
The contact resistance is rated at 100mΩ.
It operates reliably within a temperature range of -40°C to 85°C.
The contacts are made of durable silver alloy.
Yes, the relay is RoHS compliant, ensuring it meets environmental standards.
This model is designed for PCB mounting with PCB pin terminals.
It is suitable for applications in automotive engines, household appliances, industrial machinery, medical, and telecommunication equipment.
