Festo Solenoid Pilot Valve Electric G 1/8 Port Size 24V DC 5/3 Valve Function Aluminium Body CPE14-M1BH-5/3G-1/8
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 24V dc |
| Brand | Festo |
| Body Material | Aluminium |
| Maximum Operating Pressure | 8 bar |
| Model | CPE14-M1BH-5/3G-1/8 |
| Width | 14mm |
| Mount Type | Through Hole |
| Series | CPE |
| Number Of Ports | 5 |
| Maximum Operating Temperature | 50°C |
| Thread Size | 1/8 in |
| Port Type | Push-in, Threaded |
| Port Size | G 1/8 |
| Minimum Operating Temperature | -5°C |
| Actuation Type | Electric |
| Maximum Flow Rate | 800L/min |
| Standards/Approvals | c UL US, RoHS |
| Connection Thread Standard | G 1/8 |
| Minimum Pilot Pressure | 0.9bar |
| Valve Function | 5/3 |
| Maximum Pilot Pressure | 10bar |
| Port Gender | Female |
Key Features
- Operates at 24V DC voltage for reliable actuation.
- Features aluminium body for durability and resistance to mechanical stress.
- Port size G 1/8 with push-in, threaded connection.
- Maximum operating pressure of 8 bar with 5 ports configuration.
- IP65 rating provides dust-tight protection and resistance to low-pressure water sprays.
- Responsive switching-on time of 20 ms supports quick equipment startup.
- Designed for minimum operating temperature -5°C and maximum temperature of 50°C.
- Maximum pilot pressure at 10 bar and minimum pilot pressure of 0.9 bar.
Product Description
Festo CPE14-M1BH-5/3G-1/8 is a high-quality solenoid pilot valve featuring an electric actuation mechanism with a 24V DC coil. This 5/3 valve design provides a closed function that prevents air ingress or egress when de-energized, enhancing safety in control systems. The valve’s aluminium body ensures robustness against mechanical impact and abrasion, ensuring long service life in industrial environments.
The valve operates with a maximum pressure of 8 bar and supports flow rates up to 800 L/min. It includes five ports with push-in and threaded connections sized at G 1/8. It is designed to fit through-hole mounts, simplifying installation in pneumatic circuits.
Designed to function reliably across temperatures from -5°C to 50°C, the valve is suitable for demanding conditions, including pharmaceutical manufacturing, aerospace applications, and automated process industries. The IP65 rating ensures it is protected against dust and water jets, making it fit for harsh operating environments.
A throttleable exhaust feature protects equipment by selectively releasing air pressure to prevent system damage. Its rapid switching-on time of 20 milliseconds allows for efficient operation and responsiveness in automated pneumatic systems.
Operates on 24V DC electric actuation. Aluminium body delivers durability and corrosion resistance. Push-in, threaded G 1/8 ports for flexible connection options. Maximum operating pressure of 8 bar suitable for industrial pneumatic systems.
5/3 valve function with safety-closed air flow control. Robust IP65 rated construction for dusty and wet environments. Applications include pharmaceutical, aerospace, and process automation industries. Compact width of 14 mm facilitates space-saving installation.
Germany manufactured with stringent quality standards.
This Festo CPE14-M1BH-5/3G-1/8 solenoid pilot valve is an essential pneumatic component for precision fluid power control in industrial, laboratory, manufacturing, and automation sectors. Its reliable operation and robust design make it a favored choice for critical pneumatic valve functions.
Explore more Pneumatic Solenoid Valves and industrial valve accessories in the EnvMart catalog to find complementary components and solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating pressure of this model is 8 bar.
It operates at a voltage of 24V DC.
The maximum flow rate supported by this unit is 800 L/min.
This model has a width of 14 mm.
It features push-in and threaded connections with a port size of G 1/8.
It is designed to operate within a temperature range of -5°C to 50°C.
This unit is equipped with five ports.
The actuation type for this valve is electric.
It has a 5/3 valve function, which provides a closed function when de-energized.
The minimum pilot pressure is 0.9 bar.
It complies with c UL US and RoHS standards.
This solenoid pilot valve is manufactured in Germany.
