Festo 5 Pin M12X1 Straight Plug Flow Controller IP65 10V Thermal Measurement SFAM-90-15000L-M-2SA-M12

Festo SFAM-90-15000L-M-2SA-M12 5 Pin M12X1 Straight Plug Flow Controller is designed to precisely monitor changes in air consumption and flow in pipe systems or end devices. It operates autonomously or can be combined with MS series service units. Featuring a robust construction, the housing utilizes reinforced polyamide and die cast aluminium for high durability under industrial conditions.

This flow controller supports a maximum flow measurement of 15000 liters per minute with unidirectional flow input. It connects electrically through a 5 Pin M12X1 straight plug ensuring secure and easy installation. The device operates at 10V voltage supply and has a current rating of 100mA.

It is engineered to function within a temperature range from 0°C to 50°C and comes with an IP65 rating, offering excellent resistance to dust and water ingress. The illuminated blue LCD display provides real-time flow and consumption information along with threshold value monitoring and convenient switching point adjustments.

The unit supports both normally open (NO) and normally closed (NC) switching actions and follows the thermal measurement principle for accurate sensing. Certified for hazardous environments with ATEX and safety approvals such as UL E322346, it is suitable for industrial and laboratory applications.

This flow controller is ideal for monitoring energy costs effectively and detecting leaks in air lines, thereby optimizing system performance and reducing operational expenses. Its compact grid size of 62mm allows easy mounting onto service units.

Equipped with 5 Pin M12X1 straight plug electrical connection for reliable fits. Maximum flow measuring range up to 15000 liters per minute with unidirectional input from left. Housing constructed with reinforced polyamide and die cast aluminium for durability.

Operating temperature range of 0°C to 50°C suitable for industrial and lab environments. Features an illuminated blue LCD display for clear flow and consumption visualization. ATEX certified for hazardous area applications and UL E322346 certified for safety.

Monitors energy costs and enables testing of air lines for leaks efficiently. Switching action supports normally open and normally closed modes (NO/NC).

This flow controller is an essential component in pneumatic cylinder sensor applications for industrial equipment. Browse EnvMart for more high-quality pneumatic sensors and Flow Controllers by Festo and other top brands.
