KEMET 1.5 mF Surface Mount Polymer Capacitor 6.3V dc, Electrolytic, Solid Electrolyte, Package 7360-20 T520H158M006ATE055

KEMET T520H158M006ATE055 Polymer Capacitor is a 1.5 mF solid electrolyte capacitor designed as a surface mount component rated at 6.3V dc. This electrolytic capacitor delivers very low equivalent series resistance (ESR) and superior capacitance retention at high frequencies, combining features of multilayer ceramic and aluminum electrolytic capacitors.

Constructed with a conductive polymer cathode, the capacitor is contained in a compact 7360-20 package case measuring 7.3mm length, 6mm depth, and 1.9mm height. It operates reliably within a temperature range from -55°C up to 85°C and supports a ripple current of 1.8A with leakage current at 945μA.

The solid electrolyte type and polar construction yield high stability over time with no aging effects and a guaranteed operating lifetime of 2000 hours. The capacitor is halogen-free, meeting environmental considerations.

This device is ideal for industrial electronic equipment, power connectors, passive components assemblies in electronic manufacturing, and other applications requiring efficient, durable surface mount capacitors for DC voltage rails up to 6.3V.

Electrolytic polymer capacitor with low ESR and high ripple current tolerance. Compact surface mount package for space-saving PCB designs. Temperature range suited for commercial and industrial environments. Halogen-free epoxy encapsulation enhances environmental safety.

Explore our complete range of Polymer Capacitors under the KEMET brand at EnvMart for your electronic component requirements.
