Siemens 2A Motor Protection Circuit Breaker 690V 3 Poles IP20 3RV1011-1BA15
Specifications
| Country of Origin | Germany |
|---|---|
| Brand | Siemens |
| Model | 3RV1011-1BA15 |
| IP Rating | IP20 |
| Overall Length | 90mm |
| Current Rating | 2A |
| Series | 3RV1 |
| Overall Width | 45mm |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -20°C |
| Reliability | the terminal connection is resistant to shock and vibration |
| Sensing type | Current |
| Supply Voltage | 690V |
| Number of Poles | 3 |
| Standards/Approvals | CSA, EN60947, UKCA, IEC 947, VDE 0990, UL |
| Overall Depth | 81mm |
| Motor Protection Component | Circuit Breaker |
| Motor Protection System | Motor Protection Circuit Breaker |
| Time saving | the connection can be made quickly without having to press on end sleeves |
| Reduced maintenance | the cage clamp system means that the checking of screw connections following transportation is unnecessary |
Key Features
- Designed for motor feeders for special voltages including 690V.
- Compact, current limiting motor starter protector for switching and protecting induction motors.
- Equipped with an electronic release sensitive to phase failure and rotor blockage.
- Features Siemens SIRIUS Cage Clamp technology for reliable and vibration-resistant connections.
- Has an IP20 protection rating suitable for industrial environments.
- Meets standards CSA, EN60947, UKCA, IEC 947, VDE 0990, UL for safety and quality.
- Operates reliably between minimum -20°C and maximum 60°C ambient temperature.
- Manufactured in Germany ensuring high-quality engineering and durability.
Product Description
Siemens 3RV1011-1BA15 Motor Protection Circuit Breaker is a robust 2A rated, 3-pole motor protection device designed to operate at a supply voltage of 690V. It supports reliable motor protection with an operating temperature range from -20 °C to 60 °C, making it suitable for varied industrial environments.
This circuit breaker is part of the Siemens 3RV1 series, offering compact design and high short circuit breaking capacity. It effectively protects induction squirrel cage motors from overload, short circuit, phase failure, and rotor blockage through an advanced electronic release mechanism.
The product incorporates Siemens SIRIUS Cage Clamp technology, enabling quick and secure connections without the need for end sleeves. This connection system ensures resistance to shock and vibration, reducing maintenance requirements and improving overall reliability.
With an IP20 protection rating, the device is ideal for indoor industrial use where protection against physical contact is required. The compact dimensions of 90mm length, 45mm width, and 81mm depth allow for flexible installation in motor feeders and control panels.
Certified to multiple international standards including CSA, EN60947, UKCA, IEC 947, VDE 0990, and UL, this motor protection circuit breaker meets stringent safety and quality benchmarks. Its German manufacturing origin guarantees durable, high-quality construction.
Designed for motor feeders for special voltages including 690V. Compact and current limiting to protect induction motors efficiently. Electronic release sensitive to phase failure and rotor blockage. Siemens SIRIUS Cage Clamp for time-saving and reliable connections.
IP20 rated for industrial indoor environments. Compact dimensions ease integration into existing panels. Complies with multiple international safety standards. Manufactured in Germany ensuring quality and reliability.
This Motor Protection Circuit Breaker is suitable for industrial, manufacturing, automation, and electrical control applications where reliable motor protection and safety compliance are critical. Choose Siemens 3RV1011-1BA15 for enhanced motor performance and protection.
Explore more high-quality motor protection devices and circuit breakers at EnvMart to meet your industrial automation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Siemens 3RV1011-1BA15 has a current rating of 2A.
This model operates at a maximum supply voltage of 690V.
It has an IP20 protection rating, suitable for indoor industrial environments.
The operating temperature range for this unit is from -20°C to 60°C.
This motor protection circuit breaker features 3 poles.
It incorporates Siemens SIRIUS Cage Clamp technology for reliable and vibration-resistant connections.
This model meets multiple international standards, including CSA, EN60947, UKCA, IEC 947, VDE 0990, and UL.
The dimensions are 90mm in length, 45mm in width, and 81mm in depth.
It protects induction squirrel cage motors from overload, short circuit, phase failure, and rotor blockage.
The cage clamp system allows for quick and secure connections without the need for end sleeves, reducing maintenance requirements.
This motor protection circuit breaker is manufactured in Germany.
It is suitable for industrial, manufacturing, automation, and electrical control applications where reliable motor protection is critical.
