Schneider Electric LC1K Contactor, 48V AC Coil, 3-Pole, 9A, 2.2 kW Power Rating, 3 NO Contacts, 690V AC LC1K0901E7
Specifications
| Country of Origin | France |
|---|---|
| Brand | Schneider Electric |
| Function | Motor Control, Resistive Load |
| Length | 58mm |
| Model | LC1K0901E7 |
| Depth | 57mm |
| Width | 45mm |
| Mount Type | DIN Rail |
| Series | LC1K |
| Power Rating | 2.2kW |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -25°C |
| Terminal type | Screw |
| Number of Poles | 3 |
| Standards/Approvals | UL, CSA |
| Contact Voltage | 690V ac |
| Coil Voltage | 48V ac |
| Normal State Configuration | 3 NO |
| Better World Claim | Designed for Disassembly |
| Contact Current | 9A |
| Number of Auxiliary Contacts | 1 |
| Auxiliary Contact Configuration | 1 NC |
| Operational Current Ie | 9A |
| Control Circuit Voltage Uc | 48V ac |
| Contactor Application | Motor Control, Resistive Load |
| Pole and Throw Configuration | 3 |
| AC-1 | This applies to all AC devices with a power factor of at least 0.95. Example of use: resistive load, heating, distribution |
| AC-3 | This applies to squirrel cage motors where breaking occurs while the motor is running. Example of use: all squirrel cage motors, lifts, escalators, conveyors, bucket elevators, compressors, pumps, mixers, air conditioning units |
Key Features
- Compact 3-pole contactor suitable for motor and resistive load control.
- Equipped with a 48V AC coil operating at 50/60Hz frequencies.
- Includes 3 normally open (NO) contacts and 1 normally closed (NC) auxiliary contact.
- Rated for 9 amperes AC-3 and 2.2 kW power at 48V AC coil voltage.
- Features screw terminal connections and DIN rail mounting for easy installation.
- Complies with international standards including UL and CSA approvals.
- Operating temperature range from -25°C to +60°C for versatile industrial environments.
- Designed for disassembly supporting Schneider Electric's Better World sustainability initiative.
Product Description
Schneider Electric LC1K0901E7 is a robust and compact 3-pole motor control contactor featuring a 48V AC coil designed for reliable operation in industrial and commercial applications. This contactor supports motor control and resistive load functions, rated at 9A and capable of handling power up to 2.2 kW with a 48V AC coil voltage. Its compact DIN rail mount design and screw terminal connections ease installation within electrical panels.
Designed for versatility, it includes three normally open (NO) main contacts and one built-in normally closed (NC) auxiliary contact to extend control functionality. The device operates efficiently within a wide temperature range of -25°C to +60°C, making it suitable for diverse environments. It is certified to international standards including UL and CSA, reflecting Schneider Electric's commitment to quality and safety.
Additional features include its compliance with the Better World program, focused on sustainability by enabling designed-for-disassembly and recycling. Dimensions of 45mm width, 57mm depth, and 58mm length make it suitable for tight panel spaces. The contactor is optimized for powering electric motors and other resistive devices requiring AC-3 rated switching with 690V AC contact voltage.
Schneider Electric LC1K0901E7 contactor is ideal for applications such as conveyor systems, pumps, compressors, HVAC units, and general motor controls within industrial automation settings. It can be complemented with auxiliary contact blocks (LA1K, LA2K) and thermal relays (LR2K) for advanced functional control and protection.
Compact 3-pole design for motor and resistive load control. 48V AC coil suitable for 50/60Hz operation. Three NO contacts plus one NC auxiliary contact included. Screw terminal connections for secure wiring. DIN rail mounting compatibility for easy integration.
Certified UL and CSA standards compliance. Wide operating temperature range from -25°C to 60°C. Better World designed-for-disassembly sustainability feature. Compact size: 45mm width, 57mm depth, 58mm length. Manufactured in France ensuring quality assurance.
Explore more Schneider Electric automation and control gear products at EnvMart for reliable industrial solutions.
Explore more products in our Contactors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The LC1K0901E7 contactor has a power rating of 2.2 kW.
This model operates within a temperature range of -25°C to +60°C.
It is a 3-pole contactor.
It uses a 48V AC coil suitable for 50/60Hz operation.
The dimensions of the contactor are 45mm in width, 57mm in depth, and 58mm in length.
It includes three normally open (NO) contacts and one normally closed (NC) auxiliary contact.
This contactor complies with UL and CSA standards.
It is suitable for motor control and resistive load applications.
It is designed for DIN rail mounting, which facilitates easy installation.
The maximum contact voltage for the LC1K0901E7 is 690V AC.
The operational current rating is 9A.
Yes, it is suitable for applications such as conveyor systems, pumps, compressors, and HVAC units in industrial automation settings.
