SMC 2 Finger Double Acting Action Low Profile Pneumatic Gripper, Bore Diameter 12mm, Stroke Length 48mm, Maximum MHF2-12D2R



Category Pneumatic Gripper Brand SMC Condition New

Specifications

Country of Origin	Japan
Brand	SMC
Maximum Operating Pressure	0.4 Mpa
Height	25mm
Length	104mm
Model	MHF2-12D2R
Gross Weight	275g
Width	40mm
Series	MDHR2
Maximum Operating Temperature	60°C
Port Size	M5
Minimum Operating Temperature	-10°C
Stroke Length	48mm
Bore Diameter	12mm
Action Type	Double Acting
Standards/Approvals	RoHS
Number of Fingers	2
Gripping Type	Low Profile
Gripping Force - Internal	48N

Key Features

Double acting action ensures reliable gripping and release operations.
Low profile gripping type suitable for compact installations.
Operates at a maximum pressure of 0.4 Mpa for robust performance.
Series MDHR2 provides compatibility with compact auto switches that can be directly mounted.
Bore size is 12mm with stroke length specifically set at 48mm.
Gripping force is 48N both internally and externally, ensuring firm hold.
Operational temperature range spans from -10°C to 60°C.
Port size is M5 with port location at R and includes a 0.5m lead wire.

Product Description

The SMC MHF2-12D2R is a high-performance 2 Finger Double Acting Low Profile Pneumatic Gripper from the MDHR2 series. It features a bore diameter of 12 mm and a stroke length of 48 mm, designed to achieve precise grasping and releasing for automation applications.

This pneumatic gripper operates reliably under a maximum operating pressure of 0.4 Mpa and a temperature range of -10°C to 60°C, making it suitable for a variety of industrial environments. The compact low profile design with dimensions of 104 mm length, 40 mm width, and 25 mm height facilitates integration into space-constrained systems.

Gripping forces are balanced at 48N for both internal and external applications, ensuring effective object handling. The M5 port size with port location at R and a 0.5 m lead wire support smooth pneumatic and electrical connections, respectively. The unit is lightweight at 275g, contributing to efficient machine operation without adding unnecessary mass.

This model supports the direct mounting of compact auto switches, enhancing ease of use in automated systems. Double acting action design for efficient gripping and release. Low profile grip optimizes space in machinery setups.

12 mm bore diameter ensures compact yet powerful operation. 48 mm stroke length for adequate gripping range. Operates at maximum 0.4 Mpa pressure for durability. Temperature range from -10°C to 60°C suits versatile environments.

Compact dimensions aid installation flexibility. Lightweight at 275g reduces system load. RoHS compliant, ensuring environmental standards. Manufactured in Japan, upholding quality and reliability.

This pneumatic gripper is ideal for industrial automation, mechanical assembly lines, packaging machinery, and manufacturing systems requiring precise and repeatable gripping with a compact footprint.

Explore the full range of Pneumatic Grippers for tailored automation solutions at EnvMart.
