SMC Compressed Air Pipe Red Polyurethane 10 mm Outside Diameter 6.5 mm Inside Diameter 20 m Length TU Series TU1065R-20

SMC TU1065R-20 Compressed Air Pipe is a flexible polyurethane tubing with an outside diameter of 10 mm and an inside diameter of 6.5 mm, measuring 20 meters in length. This TU series product is designed specifically for conveying compressed air in industrial pneumatic systems, offering reliable performance in automation, electronics, electrical, and mechanical applications.

Constructed of polyurethane, the tubing provides excellent flexibility, resistance to kinking, and durability under demanding conditions. The maximum operating pressure rating is 0.8 MPa, ensuring optimal airflow control and consistency.

Engineered for use across temperature ranges of -20°C to 60°C, the pipe can withstand various ambient environments, with short-term tolerance near the upper limit without accelerated aging. Its compact outer diameter facilitates neat, space-saving installations in pneumatic assemblies.

Ideal applications include connection of air cylinders in automated production lines, pneumatic control panels, valve manifolds, and pick-and-place equipment for electronics assembly. Additionally, it is suited for workshop compressed air outlets, tools, and linking pneumatic sensors and small actuators.

For maintaining tubing performance, it is recommended to coil the pipe loosely, avoid sharp bends, and store away from prolonged sunlight and heat sources. Selection of compatible push-in or clamp fittings sized to the 6.5 mm internal diameter is essential for secure seals and minimal pressure loss.

Manufactured from polyurethane for enhanced flexibility and chemical resistance. Supports maximum operating pressure of 0.8 MPa for consistent compressed air delivery. Operating temperature range from -20°C to 60°C accommodates diverse industrial conditions.

Compact 10 mm outside diameter enables efficient and flexible routing in assemblies. Resists kinking to prolong service life in cyclic and dynamic equipment. Distinctive red color eases identification in complex pneumatic systems.

Designed for applications including air cylinders, control panels, valve manifolds, and electronic assembly lines.

This item is part of the SMC TU Series Compressed Air Pipe range available on EnvMart, ideal for pneumatic system design and maintenance in industrial, manufacturing, and laboratory settings.
