Wurth Elektronik WR-TBL Series Pluggable Terminal Block 5-Contact 3.81 mm Pitch 1 Row 691368300005B
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 2kV ac |
| Brand | Wurth Elektronik |
| Colour | Orange, Green |
| Orientation | Vertical |
| Current | 8A |
| Length | 19.85mm |
| Model | 691368300005B |
| Depth | 20.8mm |
| Width | 12.5mm |
| Housing Material | Polyamide |
| Series | WR-TBL |
| Number of Rows | 1 |
| Pitch | 3.81mm |
| Number of Contacts | 5 |
| Connector Gender | Male |
| Minimum Wire Size mm² | 0.08mm² |
| Maximum Wire Size mm² | 1.31mm² |
| Minimum Wire Size AWG | 28AWG |
| Maximum Wire Size AWG | 16AWG |
| Wire Connection Method | Screwless |
| Withstanding Voltage | 2.0KV AC |
Key Features
- Features a vertical orientation with a single row configuration.
- Supports a current rating of 8A for moderate power handling.
- Utilizes screwless wire connection for ease of installation.
- Accommodates wire sizes from 28 AWG to 16 AWG, with 0.08 mm² to 1.31 mm² cross section.
- Constructed with a polyamide housing offering robust insulation.
- Available in orange and green colors for identification.
- Operates reliably within a voltage of 2 kV AC withstanding capacity.
- Includes stainless steel metal springs and stainless strip steel contact material for durability.
Product Description
Wurth Elektronik 691368300005B is a pluggable terminal block designed with 5 contacts arranged in a single row and a pitch of 3.81 mm. This component is used primarily in electronic power and connector applications where reliable and robust electrical connections are required.
The terminal block features a vertical orientation and a screwless wire connection method, enabling quick and secure wiring without the need for tools. It supports wire sizes ranging from 0.08 mm² (28 AWG) up to 1.31 mm² (16 AWG), making it versatile for various wire gauges.
Manufactured with a durable polyamide housing, this terminal block offers excellent insulation and mechanical stability. The contacts are made from stainless steel metal springs and stainless strip steel, ensuring long-term corrosion resistance and conductivity.
The device is rated for a current of 8A and can withstand a voltage of 2 kV AC, making it suitable for many industrial and commercial electronic applications. Its compact dimensions (19.85 mm length, 12.5 mm width, and 20.8 mm depth) allow for efficient use of PCB space.
Additional features include compatibility with wire strip lengths of 6-7 mm and mounting via M2 screws. The terminal block is available in orange and green colors, aiding in circuit identification and installation.
This pluggable terminal block is commonly employed in industrial machinery, electronic power systems, automation equipment, and control panels, enhancing ease of maintenance and wiring flexibility.
Vertical orientation with single-row 5-contact configuration. Screwless wire connection method for tool-free installation. Polyamide housing ensures insulation and durability. Stainless steel metal springs and contacts for corrosion resistance.
Current rating of 8A and voltage withstand of 2 kV AC. Compatible with wire sizes from 28 AWG to 16 AWG. Compact dimensions: 19.85 mm x 12.5 mm x 20.8 mm. Supports wire strip lengths of 6-7 mm and M2 screw size mounting.
Available in orange and green colors for identification. Suitable for industrial, commercial, and electronic applications. Explore more in the Pluggable Terminal Blocks category at EnvMart for compatible and complementary electronic components.
Explore more products in our Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 8A, making it suitable for moderate power handling applications.
It can withstand a voltage of 2 kV AC, ensuring reliability in high-voltage applications.
This model features a pitch of 3.81 mm with a single row configuration of 5 contacts.
The housing is made of polyamide for insulation, while the contacts are constructed from stainless steel metal springs and stainless strip steel for corrosion resistance.
It utilizes a screwless wire connection method, allowing for tool-free installation and ease of use.
The compact dimensions are 19.85 mm in length, 12.5 mm in width, and 20.8 mm in depth.
This model has a vertical orientation, which is designed for efficient use in various applications.
It supports wire strip lengths of 6-7 mm, ensuring proper connection and fit.
It mounts via M2 screws, facilitating secure installation in various setups.
It is commonly employed in industrial machinery, electronic power systems, automation equipment, and control panels.
