JST JFA J300 Series Right Angle Through Hole PCB Header, 3 Contacts, 5.08 mm Pitch, 1 Row, Shrouded S03B-F32SK-GGXR

Free Delivery in India | Lowest Global Shipping Charges

JST JFA J300 Series Right Angle Through Hole PCB Header, 3 Contacts, 5.08 mm Pitch, 1 Row, Shrouded S03B-F32SK-GGXR



Category PCB Connector Brand JST Condition New

Specifications

Country of Origin	Japan
Voltage	600V
Brand	JST
Orientation	Right Angle
Current	10.5A
Model	S03B-F32SK-GGXR
Mount Type	Through Hole
Contact Material	Copper Alloy
Series	JFA J300
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-55°C
Interfaces	lances
Number of Rows	1
Pitch	5.08mm
Contact Plating	Gold
Number of Contacts	3
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board

Key Features

Designed for wire-to-board applications with a secure locking mechanism.
Constructed with copper alloy contacts plated in gold for reliable conductivity.
Rated for 10.5A current and 600V voltage with a robust operating temperature range from -55°C to 105°C.
Features double spring construction for excellent contact pressure and durability.
Ideal for industrial electronics requiring reliable PCB connections with shrouded, right angle mounting.
Secure locking method prevents unintended disconnection during operation.
Housing lances increase mechanical stability under vibration and shock.
Polarization by key codes prevents mismatching during assembly.

Product Description

The JST S03B-F32SK-GGXR right angle PCB header is part of the JFA J300 series designed for efficient wire-to-board connection assembly on printed circuit boards. Featuring a 3-contact count with 5.08 mm pitch and single row configuration, this shrouded header ensures secure mating with complementary J-FAT spring terminal connectors. The housing includes lances for added stability and polarization keys to prevent incorrect coupling.

With copper alloy contacts plated in gold, the header offers superior electrical conductivity and corrosion resistance. The double spring design provides reliable contact pressure adjustment suitable for wire sizes 14-28 AWG. Rated at 10.5 amps and 600 volts, it supports demanding electrical requirements and operates effectively in a wide temperature range from -55°C to 105°C. The through hole mount type simplifies soldering on PCB assemblies.

This product is manufactured in Japan and conforms to UL 94V-0 flammability standards, ensuring safety and reliability. Although it carries no additional certifications, it is widely used in electronic components, industrial automation, and manufacturing sectors for robust PCB interconnections.

The JFA J300 Series PCB header is ideal for industrial, laboratory, and commercial electronic equipment applications where secure wire-to-board connections and durability are paramount. Its shrouded right angle design aids in reducing assembly errors while maintaining compact PCB layouts.

Secure locking method prevents unintended disconnection during operation. Housing lances increase mechanical stability under vibration and shock. Polarization by key codes prevents mismatching during assembly. Suitable for automation and factory assembly processes for high volume production.

Supports multiple AWG wire sizes for flexible wiring options. This JST PCB header represents a reliable and precise connector solution for electronics manufacturing, available through EnvMart under the electronics connectors category.
