ABB Fuse Switch Disconnector 4-Pole 32A DIN Rail Mount E90 Series 2CSM204723R1801 E 94/32

ABB 2CSM204723R1801 E 94/32 fuse switch disconnector is a 4-pole, 32 ampere rated electrical safety device designed for mounting on DIN rails. It belongs to the E90 series which is specifically engineered to safely connect and disconnect electrical circuits under load, providing protection against short circuits and overloads. The fuse switch disconnector is suitable for use in industrial, commercial, HVAC, and manufacturing electrical panels.

The device supports 3-phase electrical systems and features a mechanical fuse size standard of 10 x 38 millimeters, designed to accommodate compatible fuses ensuring reliable protection. It carries an IP20 rating which protects against accidental contact with the internal components and solid foreign objects larger than 12 millimeters.

The outer casing is made from a self-extinguishing thermoplastic material, offering high resistance to elevated temperatures up to a maximum of 140°C, thereby enhancing operational safety. The contact tips inside are manufactured with silver-plated copper, ensuring excellent electrical conductivity and durability for long-term use.

For safety during maintenance, the fuse switch disconnector can be sealed or padlocked to prevent unauthorized access or accidental operation. The product conforms to relevant international standards including U certification, IEC 60947-3, and IEC 60269 series, guaranteeing compliance with rigorous safety and performance requirements.

Manufactured in Germany, this switch disconnector is engineered for easy and quick installation with compatibility for connecting bars, terminals, and caps of S 200 miniature circuit breakers (MCBs). It is ideal for use in the electrical distribution networks of factories, commercial buildings, and water treatment plants where reliable circuit protection and operator safety are critical.

The product is designed for DIN rail mounting installation. It supports 3-phase electrical systems for industrial and commercial applications. E90 series ensures safe connection and disconnection under load conditions. The device features an IP20 rating providing protection against solid objects larger than 12 mm.

Mechanical fuse size supports 10 x 38 mm standard fuses. Maximum operating temperature rating is 140 degrees Celsius suitable for demanding environments. It complies with international standards including U, IEC 60947-3, IEC 60269 series for safety and quality.

The case material is self-extinguishing thermoplastic resistant to high temperatures. Contact tips are crafted from silver-plated copper to enhance conductivity and durability. Fuse-disconnectors can be sealed or padlocked to enhance operator safety during maintenance.
