Phoenix Contact Angled Wave Soldering Mount PCB Terminal Block 12 Contacts 3.5 mm Pitch 160V 16A 2 Rows SPTAF 1862149

Free Delivery in India | Lowest Global Shipping Charges

Phoenix Contact Angled Wave Soldering Mount PCB Terminal Block 12 Contacts 3.5 mm Pitch 160V 16A 2 Rows SPTAF 1862149

Name: Phoenix Contact Angled Wave Soldering Mount PCB Terminal Block 12 Contacts 3.5 mm Pitch 160V 16A 2 Rows SPTAF 1862149
Brand: PHOENIX CONTACT
SKU: 214628
Price: 5.05 USD
Availability: InStock



Category PCB Terminal Block Brand PHOENIX CONTACT Condition New

Specifications

Country of Origin	India
Voltage	160V
Brand	Phoenix Contact
Orientation	Angled
Current	16A
Model	1862149
Mount Type	Wave Soldering Mount
Housing Material	Polyamide
Series	SPTAF 1/12-3.5-EL
Number of Rows	2
Pitch	3.5mm
Standards/Approvals	EU RoHS, cULus Recognised
Number of Contacts	12
PCB Terminal block, nominal current	16 A, nom. voltage: 160 V, pitch: 3.5 mm, number of positions: 12, connection method: Push-in spring connection, mounting: Wave soldering, conductor/PCB connection direction: 45 °, Colour: green

Key Features

Push-in spring connection allows tool-free and time-saving mounting.
Wave soldering mount suitable for stable and reliable PCB attachment.
Two rows orientation with 45 ° conductor/PCB connection direction for space-efficient design.
Green polyamide housing ensures durable insulation and mechanical strength.
Integrated test option enables quick and convenient functionality verification.
Finger-operated release button provides ease of operation and maintenance.
Compact size suitable for applications requiring minimal space consumption.
Complies with EU RoHS and cULus recognitions ensuring environmental and safety standards.

Product Description

Phoenix Contact 1862149 is an angled wave soldering mount PCB terminal block with 12 contacts, offering a 3.5 mm pitch and rated for 16 amperes at 160 volts. Its push-in spring connection technology provides a reliable and tool-free wire termination method, making installation and maintenance efficient and straightforward.

Designed with a two-row configuration, this terminal block features a conductor/PCB connection direction angled at 45 degrees, enabling effective space saving in PCB layouts. The housing is made from green polyamide, providing robust insulation properties and mechanical durability suited for industrial environments.

The terminal block supports wave soldering mount, ensuring excellent solder joint quality and mechanical stability on the PCB. It includes an integrated test option permitting rapid testing without disconnection, enhancing troubleshooting convenience.

Operation is facilitated by a finger-operated release button, allowing quick wire release and reconnection without specialized tools. This product complies with EU RoHS and holds cULus recognition, underscoring its adherence to environmental and safety standards in electronics manufacturing.

Its compact form factor and reliable contact force make it well adapted for applications where space is limited but performance cannot be compromised, including industrial control, automation systems, and power distribution modules.

Push-in spring connection allows tool-free and time-saving mounting. Wave soldering mount ensures stable PCB attachment. Two rows, angled 45 ° conductor/PCB connection direction. Green polyamide housing offers strong insulation.

Integrated test option enables efficient testing. Finger-operated release button for ease of wire handling. Compact design fits space-constrained applications. Complies with EU RoHS and cULus approval standards. Rated at 16 A nominal current, 160 V nominal voltage.
