JAE IL-AG5 Series Automotive Connector Female Yellow Cable 30 Way Crimp Termination IL-AG5-30S-D3C1

The JAE IL-AG5-30S-D3C1 is a high-quality automotive connector designed for reliable cable connection with 30 female contacts arranged in two rows. The yellow socket housing made of polybutylene terephthalate offers robust physical and environmental protection, ideal for demanding automotive instrument panel applications.

This connector supports a current rating of 3 amps and features tin-plated contacts that ensure excellent conductivity and corrosion resistance. The crimp termination type provides a secure and stable electrical connection, ensuring long-term reliability in automotive environments.

Designed with advanced mechanical and double lock mechanisms, the connector prevents contact dislodgement and mismating errors. Its unique housing configuration further assists in correct mating, facilitating easier installation and maintenance.

The operating temperature range from -40°C to 85°C allows this connector to perform effectively in harsh environments, making it suitable for automotive, industrial, and other electrical systems requiring multi-contact connectivity.

Dimensionally, the connector measures 46.7mm in width, 16.6mm in height, and 24.6mm in depth, providing a compact form factor compatible with many applications. No cord is included with this component.

This connector is widely used in automotive electrical systems, instrument panels, and wiring harnesses. The product offers improved production efficiency by packaging ready for insertion into machinery. Its design eliminates the risk of improper contact alignment for safe and trusted operation.

It meets general connector standards for durability and mechanical retention. JAE's IL-AG5 series connectors are known for their high reliability in automotive electronics. Explore more Automotive Connectors and accessories available in the Electronics & Electricals category on EnvMart.
