Alpha Wire Ecogen Ecowire Series Purple 0.13 mm² Hook Up Wire 26 AWG, 7/0.16 mm Strands, 30 m Length, Modified 6711 VI005

Free Delivery in India | Lowest Global Shipping Charges

Alpha Wire Ecogen Ecowire Series Purple 0.13 mm² Hook Up Wire 26 AWG, 7/0.16 mm Strands, 30 m Length, Modified 6711 VI005

Name: Alpha Wire Ecogen Ecowire Series Purple 0.13 mm² Hook Up Wire 26 AWG, 7/0.16 mm Strands, 30 m Length, Modified 6711 VI005
Brand: ALPHA WIRE
SKU: 212026
Price: 38.6 USD
Availability: InStock



Category Hook Up Wire Brand ALPHA WIRE Condition New

Specifications

Country of Origin	India
Voltage	600V
Brand	Alpha Wire
Colour	Violet
Temperature range	-40°C to +105°C
CROSS SECTIONAL AREA	0.13mm²
Model	6711 VI005
Cable Length	30m
Series	Ecogen Ecowire
Outside diameter	0.97mm
Maximum Operating Temperature	105°C
Conductor Material	Copper
Sub Type	EcoWire
Minimum Operating Temperature	-40°C
Conductor Size	26 AWG
Jacket Material	Modified Polyphenilether
Standards/Approvals	CE, CSA, UL
Jacket Colour	Purple
Fire Behaviour	Halogen Free
American Wire Gauge	26AWG
Number of Strands	7
Core Strands	7 x 0.16mm
Size of Strands	0.16mm
Stranding	7/34 AWG

Key Features

Constructed with 7 strands of 0.16 mm diameter copper wires for flexible and reliable electrical connections.
Rated for 600 V voltage and designed with halogen-free, flame retardant modified polyphenylether insulation.
EcoWire technology makes the wire fully recyclable and environmentally friendly.
Offers excellent dielectric strength and up to 45% smaller diameter than equivalent PVC wires.
Suitable for use in control panels, automotive wiring, electronic equipment, and appliances.
Meets CE, CSA, UL, RoHS, and REACH compliance standards for safety and sustainability.

Product Description

Alpha Wire 6711 VI005 is a high-performance Hook Up Wire from the Ecogen Ecowire Series featuring a 0.13 mm² cross-sectional area with 7 strands of 0.16 mm copper conductor, encapsulated in a durable, modified polyphenylether (mPPE) jacket colored purple. The wire is 30 meters long and supports 600 V with an operating temperature range of -40°C to 105°C.

This EcoWire product combines excellent electrical insulation properties with environmentally conscious design by being fully recyclable and halogen-free. The modified polyphenylether jacket provides flame retardant characteristics meeting UL VW-1 standards, ensuring enhanced safety in demanding industrial and commercial applications.

Its compact diameter of 0.97 mm allows up to 45% space saving compared to PVC insulated wires, while being 40% lighter, facilitating easier installation and handling.

Applications include wiring in control panels, automotive systems, electronic machinery, meters, ovens, computers, and other electronic appliances requiring highly reliable conductors with certified safety approvals.

Compliant with international standards such as CE, CSA, UL, RoHS, and REACH, the Alpha Wire Ecogen Ecowire Series ensures top-tier quality, safety, and eco-friendly performance. Fully recyclable material reduces environmental impact.

Halogen-free with flame retardant to UL VW-1 rating. Enhanced dielectric properties enable reduced insulation thickness. Ideal for industrial, automotive, laboratory, and commercial electrical wiring. Stranded copper conductor provides excellent flexibility and conductivity.

Jacket color coding aids identification and system organization. Explore more wire and cable solutions from Alpha Wire and the Ecogen Ecowire Series at EnvMart for your electrical and automation needs.
