KEMET Aluminium Cylindrical Can Capacitor 0.18F 25V DC Polar Screw Mount ALS80A184KF025
Specifications
| Country of Origin | Portugal |
|---|---|
| Voltage | 25V dc |
| Diameter | 51mm |
| Brand | KEMET |
| Height | 105mm |
| Length | 105mm |
| Model | ALS80A184KF025 |
| Mount Type | Screw |
| Construction | Cylindrical Can |
| Series | ALS80 |
| Termination Type | Screw |
| Maximum Operating Temperature | 105°C |
| Tolerance | ±20 % |
| Lifetime | 11000 h |
| Capacitance | 0.18F |
| Minimum Operating Temperature | -40°C |
| Polarity | Polar |
| Leakage Current | 6mA |
| Standards/Approvals | RoHS, IEC 60384-4 |
| Pin Count | 2 |
| Lead Pitch | 22.2mm |
| Equivalent Series Resistance ESR | 13mΩ |
| Capacitor Ripple Current | 18.7A |
Key Features
- The capacitor features a cylindrical can construction for high reliability.
- It has a capacitance of 0.18 Farads suitable for various power applications.
- Rated for 25 volts DC operation with a polar configuration.
- Mounting is by screw type termination for secure connection.
- The capacitor dimensions are 105mm in length and height, and 51mm diameter.
- It supports capacitor ripple current up to 18.7A ensuring robust performance.
- Operating temperature ranges from -40°C minimum to 105°C maximum.
- Leakage current is minimal at 6mA ensuring low energy loss.
Product Description
KEMET ALS80A184KF025 aluminium cylindrical can capacitor is designed for high reliability and long-life applications in electronic components. It features a screw mount termination type and a polar configuration suitable for DC voltage applications.
This capacitor has a capacitance value of 0.18 Farads and is rated for 25 volts DC operation. The robust cylindrical can construction enhances volumetric efficiency, allowing maximum capacitance in a compact size. Measuring 105mm in length and height with a 51mm diameter, it is ideal for high current ripple environments.
It supports a capacitor ripple current of 18.7A, making it suitable for demanding industrial and power supply applications like frequency converters, uninterruptible power supply (UPS) systems, and switch mode power supplies (SMPS). The capacitor operates reliably within a temperature range of -40°C to 105°C, allowing extended temperature performance and increased ripple currents at lower temperatures.
The device features a very low leakage current of 6mA and an equivalent series resistance (ESR) of 13 milliohms, contributing to energy efficiency and thermal stability. It has a rated lifetime of approximately 11000 hours, ensuring durability in industrial, electrical, and electronic applications.
This capacitor complies with RoHS and IEC 60384-4 standards, reflecting its manufacturing quality and safety. Manufactured in Portugal, it belongs to the ALS80 series known for high CV screw terminal capacitors that meet industrial reliability standards.
The capacitor features a cylindrical can construction for high reliability. It has a capacitance of 0.18 Farads suitable for various power applications. Rated for 25 volts DC operation with a polar configuration. Mounting is by screw type termination for secure connection.
The capacitor dimensions are 105mm in length and height, and 51mm diameter. It supports capacitor ripple current up to 18.7A ensuring robust performance. Operating temperature ranges from -40°C minimum to 105°C maximum. Leakage current is minimal at 6mA ensuring low energy loss.
Equivalent series resistance is 13mΩ improving efficiency and longevity. It has a lifetime expectancy of 11000 hours under standard conditions.
This product is suitable for industrial, electrical, and power electronics manufacturing, laboratories, and power supply system maintenance. Explore EnvMart’s catalogue for KEMET and related Aluminium Capacitors used in high reliability and long-life electronic circuits.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a capacitance of 0.18 Farads, making it suitable for various power applications.
It is rated for a maximum voltage of 25 volts DC operation.
The capacitor measures 105mm in length and height, with a diameter of 51mm.
This unit features a screw mount termination type for secure connection.
It supports a capacitor ripple current of up to 18.7A, ensuring robust performance in demanding applications.
The operating temperature range is from -40°C to 105°C, allowing for extended performance in various conditions.
The leakage current is minimal at 6mA, contributing to low energy loss.
The equivalent series resistance (ESR) is 13 milliohms, which helps improve efficiency and longevity.
This capacitor complies with RoHS and IEC 60384-4 standards, reflecting its manufacturing quality and safety.
This model is manufactured in Portugal.
