Molex KK 254 Series Right Angle Through Hole Pin Header 3 Contacts 2.54 mm Pitch 1 Row Unshrouded 22-12-2034

Free Delivery in India | Lowest Global Shipping Charges

Molex KK 254 Series Right Angle Through Hole Pin Header 3 Contacts 2.54 mm Pitch 1 Row Unshrouded 22-12-2034

Name: Molex KK 254 Series Right Angle Through Hole Pin Header 3 Contacts 2.54 mm Pitch 1 Row Unshrouded 22-12-2034
Brand: Molex
SKU: 209248
Price: 0.83 USD
Availability: InStock



Category Electronics Components Brand Molex Condition New

Specifications

Country of Origin	Mexico
Voltage	250V
Brand	Molex
Orientation	Right Angle
Current	4A
Mount Type	Through Hole
Housing Material	Nylon
Contact Material	Brass
Series	KK 254
Termination Type	Solder
Maximum Operating Temperature	80°C
Minimum Operating Temperature	-40°C
Number of Rows	1
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	3
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Wire-to-Board

Key Features

Features a right angle orientation for PCB mounting.
Constructed with a nylon housing for durability and UL 94V-0 compliance.
Uses brass contacts with gold plating for reliable conductivity.
Supports a current rating of 4A and voltage up to 250V.
Designed as an unshrouded, 1-row pin header suitable for through-hole soldering.
Operating temperature range from -40°C to 80°C ensures robust performance.
Compatible with 2695 Series Housings with friction lock for secure connections.

Product Description

Molex 22-12-2034 KK 254 Series Right Angle Through Hole Pin Header is a high-quality electronic connector designed for wire-to-board applications requiring robust and reliable PCB connections. The connector features 3 contacts arranged in a single row with a 2.54 mm pitch, ideal for standard PCB footprints.

The housing is fabricated from durable white nylon rated UL 94V-0 for flame retardance, supporting extended use in industrial and commercial electronic equipment. Brass contacts plated with gold ensure excellent electrical conductivity and corrosion resistance, enhancing the life and reliability of the connection.

Operating within a temperature range of -40°C to 80°C and supporting up to 4 amps of current and 250 volts, it is suitable for various electronic, industrial, and manufacturing environments.

The pin header features a right angle orientation to allow compact PCB layouts, and as an unshrouded pin header, it provides easy access for soldering and installation. This product is compatible with Molex 2695 Series housings with friction lock, enabling secure wire retention and reliable performance in demanding applications.

Used widely in electronic assembly lines, power connectors manufacturing, automated equipment interfaces, and testing fixtures, this connector ensures consistent performance and ease of integration.

Right angle orientation simplifies PCB layout design and saves space. Durable nylon housing meets UL 94V-0 standards for safety. Brass contacts with gold plating guarantee excellent connectivity. Rated for 4A current and 250V voltage, suitable for moderate power applications.

Compatible with Molex 2695 housing series for secure connections.

This Molex KK 254 Series Right Angle Through Hole Pin Header is a reliable choice for industrial electronics, consumer devices, and commercial electronic product manufacturing processes. Explore related PCB connectors and headers in the Electronics & Electricals category at EnvMart to find compatible components for your projects or production lines.

Explore more products in our Electronics Components category.
