Bourdon 63 mm G 1/4 Pressure Gauge, 6 bar, Stainless Steel Case, Back Entry MIT3-F20.B20
Specifications
| Country of Origin | China |
|---|---|
| Accuracy | ±1.6 % |
| Brand | Bourdon |
| Model | MIT3-F20.B20 |
| Case Material | Stainless Steel |
| Series | MIT3 |
| Maximum Operating Temperature | 70°C |
| Dial Size | 63mm |
| Connection Size | G 1/4 |
| PRESSURE CONNECTION | Brass |
| Maximum Pressure Measurement | 6bar |
| Minimum Pressure Measurement | 0bar |
| Connection Location | Back Entry |
| Dial Colour | White, Black |
| RS PRO, 63 mm BSP 1/4 in 1/4 in BSP Pressure Gauge, 6 barRS Stock No. | 179-984Brand: RS PRO |
Key Features
- Features high accuracy ±1.6% for precise pressure measurement.
- Constructed with a stainless steel case and cupreous metal Bourdon tube for durability.
- Back entry connection location with 14 mm hexagonal brass fitting.
- Dial is white with black graduations for clear readability.
- Maximum operating temperature is 70°C, suitable for various industrial environments.
- Designed to conform to EN 837-1 standards and pressure PED 97/23/CE compliance.
- IP54 rated for protection against dust and splashing water.
Product Description
Bourdon MIT3-F20.B20 pressure gauge features a 63 mm diameter dial and is designed for measuring pressures up to 6 bar with precision and reliability. The instrument incorporates a stainless steel case and a cupreous metal Bourdon tube with a welded tube connection assembly, ensuring long-term durability in demanding industrial applications.
The gauge dial has easy-to-read black graduations on a white background complemented by a black balanced aluminium pointer. It has a back entry G 1/4 brass connection, employing a 14 mm hexagonal fitting, facilitating straightforward integration into piping systems. This pressure gauge is built to conform to EN 837-1 standards and carries compliance with Pressure PED 97/23/CE and NF EN 60529 directives, guaranteeing safety and performance.
With an accuracy class of ±1.6%, it is suitable for a wide range of industrial and commercial uses, including compressors, diesel engines, agricultural equipment, hydraulic systems, pumps, and machine tools. Its maximum operating temperature is 70°C, and the IP54 rating offers effective protection against dust ingress and water splashes, ensuring reliability even in challenging environments.
High accuracy ±1.6% for reliable measurements. Durable stainless steel case and Bourdon tube assembly. Back entry connection with G 1/4 brass fitting for easy installation. Clear dial with black graduations on a white background.
Conforms to EN 837-1 and Pressure PED 97/23/CE standards. IP54 protection allowing use in industrial and outdoor environments. Applications include compressors, agricultural equipment, and hydraulic systems.
This Bourdon pressure gauge is manufactured in China, offering reliable performance in laboratory, manufacturing, construction, HVAC, and agricultural sectors. Environmental conditions demanding moderate temperature and protection requirements are well accommodated by this robust instrument.
Browse EnvMart’s comprehensive range of Pressure Gauges and measuring instruments for industrial and technical applications.
