Bourdon 63 mm Stainless Steel Bottom Entry Pressure Gauge G 1/4, 0 to -1 bar, Class 2.5 Accuracy MIT3-D20.B59

Bourdon MIT3-D20.B59 is a precision pressure gauge featuring a 63 mm diameter dial housed in a stainless steel case, designed for bottom entry connection of size G 1/4 inch to measure pressure accurately in the range from 0 to -1 bar. The dial has black graduations and numbering on a white background for clear visibility, complemented by a black balanced aluminum pointer.

The gauge complies with the EN 837-1 standard for pressure measurement instruments and is classified as Class 2.5 for accuracy, ensuring reliable readings with an error margin of ±2.5%. It is suitable for measuring pressures in compressors, diesel engines, agricultural machinery, machine tools, hydraulic systems, and pumps.

The robust stainless steel case protects the internals from mechanical damage and environmental conditions, allowing operation up to a maximum temperature of 70°C. The cupreous metal Bourdon tube and welded tube connection assembly guarantee durability and long service life. The brass hexagonal connection (14 mm) is designed for ease of installation and secure attachment.

This pressure gauge is rated with an ingress protection of IP54 for the 63 mm diameter model, safeguarding it against dust and splashing water. It aligns with European standards EN 837-1, NF EN 60529, and the Pressure Equipment Directive 97/23/CE, ensuring product safety and conformity.

The pressure connection size is standard G 1/4 inch for bottom entry fitting. The dial size of 63 mm provides clear and precise pressure readout. The case and connection materials are stainless steel and brass respectively, for enhanced corrosion resistance.

Class 2.5 accuracy ensures precise measurement for engineering and industrial applications. Durable construction suited for harsh environments and varying temperatures up to 70°C. Ideal for use in pneumatic and hydraulic systems, machine tool monitoring, pumps, and general industrial equipment.

This Bourdon pressure gauge is manufactured in China and comes new from the factory. It is a trusted instrument for pressure measurement in commercial, industrial, agricultural, and mechanical engineering contexts. Available as a reliable solution for maintenance and operational control of fluid power systems.
