Bourdon 40 mm G 1/8 Pressure Gauge 6 bar MAT1-F10.B20

Bourdon MAT1-F10.B20 Pressure Gauge is a high-quality mechanical pressure measuring instrument with a 40 mm dial diameter and a maximum pressure capacity of 6 bar. It is engineered with a robust black painted steel case for industrial durability and features a precise black aluminium knife edge pointer on a white dial, making readings clear and accurate.

This Pressure Gauge is designed with a back entry connection of size G 1/8, facilitating straightforward installation in pneumatic and hydraulic systems. It meets the industry standards EN 837-1 and Pressure PED 97/23/CE, ensuring compliance with regulatory and safety requirements.

With an accuracy rating of ±2.5 %, this gauge delivers reliable performance in a variety of applications such as compressed gases, lubricating circuits, and hot or cold water networks. The device supports operation at temperatures up to 70°C, making it suitable for a broad range of industrial environments.

The construction includes a cupreous metal Bourdon tube and welded tube connection assembly along with a brass connection featuring a 14 mm square, enhancing the durability and precision of pressure sensing. The IP32 rating provides protection against dust and mechanical impact, ensuring longevity in typical working conditions.

This gauge is manufactured in China, reflecting consistent quality as part of Baumer's MAT series. It caters to industrial, mechanical, fluid power, pneumatic, and hydraulic uses, and is an essential tool for pressure monitoring and control.

The gauge casing is made of black painted steel, providing ruggedness. Features a white dial with clear black graduations for visibility. The pointer is knife edge black aluminium, ensuring precise indication. Back entry connection size G 1/8 allows versatile installation options.

Accurate to ±2.5 %, meeting demanding industrial measurement needs. Operates under a maximum temperature of 70°C. Complies with EN 837-1 and Pressure PED 97/23/CE safety and quality standards. Ideal for compressed gases, lubricating circuits, and water distribution systems.

Durable cupreous Bourdon tube and brass fittings enhance lifespan. Discover more technical measurement instruments in our Industrial Machines & Instruments category at EnvMart.
