Bourdon Industrial 100 mm Stainless Steel Bottom Entry Pressure Gauge 4 bar MEX5-D30.B19
Specifications
| Country of Origin | China |
|---|---|
| Accuracy | ±1 % |
| Brand | Bourdon |
| Model | MEX5-D30.B19 |
| Connection Type | Bottom |
| Case Material | Stainless Steel |
| Series | MEX5 |
| Maximum Operating Temperature | 70°C |
| Dial Size | 100mm |
| Connection Size | G 1/2 |
| PRESSURE CONNECTION | G 1/2 |
| Maximum Pressure Measurement | 4bar |
| Minimum Pressure Measurement | 0bar |
| Connection Location | Bottom Entry |
| Dial Colour | White |
| RS PRO, 100 mm G 1/2 Pressure Gauge, 4 barBrand | RS PRO |
| RS PRO, 100 mm G 1/2 Pressure Gauge, 4 barRS Stock No. | 258-2352Brand: RS PRO |
Key Features
- High accuracy with ±1% tolerance for precise measurements.
- Constructed with stainless steel case and wetted parts for durability and corrosion resistance.
- Bottom entry connection fitting of G 1/2 size for installation flexibility.
- Operates effectively at maximum temperatures up to 70°C.
- Instrument glass window includes an elastomer seal and blowout device for operator safety.
- Designed for applications in food, beverage, laboratory, oil gas, chemical, water, energy, transportation, and machinery sectors.
- Complies with ATEX II2GDc-IM2c, EN 60529 (IP 65), EN 837-1 standards, and holds Lloyds Register Approval.
- Manufactured in China with a robust design to withstand industrial environments.
Product Description
Bourdon MEX5-D30.B19 is a high-quality industrial pressure gauge featuring a 100 mm diameter dial and bottom entry connection type suitable for measuring pressures up to 4 bar with high accuracy of ±1%.
The gauge is constructed with a stainless steel case and wetted parts ensuring excellent resistance against corrosive gases and liquids, making it ideal for demanding industrial environments.
Its white dial face with black lettering offers clear readability, and it is fitted with a high-grade instrument glass window including an elastomer seal and a blowout safety device to protect operators.
The pressure connection size is G 1/2 with a bottom entry location, providing ease of installation and compatibility with standard pneumatic and hydraulic systems. It operates reliably up to a maximum temperature of 70°C.
This pressure gauge complies with key industry standards including ATEX II2GDc-IM2c for hazardous areas, IP 65 for ingress protection, EN 837-1 for pressure measurement, and has Lloyds Register Approval along with a material certificate 3.1 EN10204.
Applications span across food and beverage processing, laboratory and medical equipment, oil and gas, chemical processing, water and wastewater management, energy sectors, transportation, logistics, and various machinery.
Set contains 1 Pressure Gauge with 100 mm dial size, stainless steel construction, and bottom connection suitable for precise industrial pressure measurement tasks. High accuracy with ±1% tolerance for precise measurements.
Stainless steel construction offers corrosion resistance and durability. G 1/2 bottom connection type for versatile mounting options. Operating temperature up to 70°C. Compliant with ATEX, IP 65, EN 837-1, Lloyds Register standards.
Suitable for multiple industrial applications including laboratories and process industries. Robust instrument glass window with elastomer seal and blowout device for safety. Material certificate 3.1 EN10204 ensures traceability and quality.
Explore more industrial Pressure Gauges and measuring instruments on EnvMart to find products suited for your specific application needs.
