Bourdon 50 mm G 1/4 Pressure Gauge, 6 bar, Black Painted Steel Case, ±2.5% Accuracy MAT2-F20.B20

The Bourdon MAT2-F20.B20 is a mechanical pressure gauge designed for accurate measurement of pressures up to 6 bar. Featuring a 50 mm dial size, this gauge offers clear and reliable readings for various industrial and laboratory applications. The black painted steel case provides robust protection, while the white dial with black graduations enhances visibility. It includes a knife edge black aluminium pointer rated to Class 2.5 accuracy, ensuring precise measurements.

This pressure gauge is built to conform with industry standards PED 97/23/CE and EN 837-1, assuring quality and safety in operation. The pressure connection is a G 1/4 inch with a back entry location, enabling convenient installation in compressed gas systems, lubricating circuits, and hot or cold water networks.

The maximum operating temperature for this unit is 70°C, providing versatility across different environments. Its components include a cupreous metal Bourdon tube, a welded tube connection assembly, and a brass connection with a 14 mm square.

Applications for this gauge include monitoring pressure in compressed gases, lubricating circuits, and water distribution systems in industrial, HVAC, manufacturing, and water treatment settings. The compact and durable design makes it suitable for both commercial and industrial usage.

Black painted steel case for enhanced durability. Accurate to ±2.5%, class 2.5. 50 mm dial size with white dial and black graduations. Pressure connection G 1/4 inch, back entry. Maximum pressure measurement 6 bar with 0 bar minimum.

Max operating temperature 70°C for versatile use. Conforms to PED 97/23/CE and EN 837-1 standards. Knife edge black aluminium pointer for precision. Suitable for compressed gases, lubricating and water circuits. Explore more Pressure Gauges and measuring instruments at EnvMart for reliable industrial solutions.
