Bourdon 40 mm 1/8 in G Threaded Pressure Gauge 16 bar MAT1-F10.B24

Bourdon MAT1-F10.B24 pressure gauge features a 40 mm diameter dial with clear white background and black graduations, providing precise pressure measurement up to a maximum of 16 bar.

The pressure gauge is constructed with a black painted steel case which enhances its durability and resists corrosion in industrial environments. It employs a brass connection of 1/8 in G size and threaded type with a back entry connection location for convenient installation.

This gauge utilizes a cupreous metal Bourdon tube and a welded tube connection assembly ensuring accurate and reliable readings. The black aluminium knife edge pointer along with a Kostil technopolymer dial guarantees excellent visibility of measurements. The unit is IP32 rated, providing protection against solid objects and limited water ingress.

Accuracy is maintained at ±2.5%, conforming to EN 837-1 standards and certified to PED 97/23/CE. It is capable of operating at temperatures up to 70°C, making it suitable for a wide range of industrial applications including compressed gases, lubricating circuits, and hot or cold water networks.

Black painted steel case ensures durability and resistance to harsh environments. White dial face with black graduations and black aluminium pointer for clear readability. Brass 1/8 in G threaded connection with back entry for easy mounting.

Cupreous metal Bourdon tube provides reliable pressure sensing. Compliance with PED 97/23/CE and EN 837-1 standards ensures quality and safety. Maximum pressure measurement capability of 16 bar. Operating temperature up to 70°C for versatile use.

IP32 rated protection against solids and limited water ingress. Suitable for pneumatic and hydraulic pressure measurement in industrial, laboratory, and HVAC applications.

This Bourdon pressure gauge delivers precision and durability for demanding environments in industries like fluid power systems, water treatment, and manufacturing. Browse more Pressure Gauges and measuring instruments on EnvMart for complete instrument solutions.
