Bourdon 40 mm G 1/8 Pressure Gauge 4 bar MAT1-F10.B19

Free Delivery in India | Lowest Global Shipping Charges

Bourdon 40 mm G 1/8 Pressure Gauge 4 bar MAT1-F10.B19

Name: Bourdon 40 mm G 1/8 Pressure Gauge 4 bar MAT1-F10.B19
Brand: Bourdon
SKU: 205820
Price: 13.91 USD
Availability: InStock



Category Pressure Gauges Brand Bourdon Condition New

Specifications

Country of Origin	China
Accuracy	±2.5 %
Brand	Bourdon
Model	MAT1-F10.B19
Case Material	Black Painted Steel
Series	MAT
Maximum Operating Temperature	70°C
Dial Size	40mm
Connection Size	G 1/8
Standards/Approvals	EN 837-1, Pressure PED 97/23/CE
Maximum Pressure Measurement	4bar
Minimum Pressure Measurement	0bar
Connection Location	Back Entry
Dial Colour	White

Key Features

Black painted steel case ensures durability and corrosion resistance.
White dial with black graduations for clear readability.
Back entry G 1/8 connection for easy installation.
Maximum operating temperature up to 70°C suitable for various industrial environments.
Complies with EN 837-1 and Pressure PED 97/23/CE standards for quality assurance.
Ideal for measuring pressure in compressed gases and water networks.
Knife edge black aluminium pointer improves measurement precision.
IP32 rated protection against ingress of solid objects.

Product Description

Bourdon MAT1-F10.B19 is a 40 mm diameter pressure gauge designed to accurately measure pressures from 0 to 4 bar. The gauge features a durable black painted steel case with a white dial and clear black graduations to facilitate easy reading in industrial settings.

The connection size is G 1/8 with a back entry configuration, allowing flexible mounting options. This pressure gauge operates effectively up to a maximum temperature of 70°C, making it suitable for various pneumatic and hydraulic applications.

Compliance with EN 837-1 and Pressure PED 97/23/CE standards ensures reliable performance and regulatory adherence. The gauge’s knife edge black aluminium pointer and IP32 rating provide precise indication and protection against solid ingress, respectively.

Constructed with a cupreous metal Bourdon tube and a welded tube connection assembly, this gauge guarantees durability and measurement accuracy within ±2.5%. It is well-suited for industrial environments such as compressed gases, lubricating circuits, and hot or cold water distribution networks.

Black painted steel case ensures durability and corrosion resistance. White dial with black graduations for clear readability. Back entry G 1/8 connection for easy installation. Maximum operating temperature up to 70°C suitable for various industrial environments.

Complies with EN 837-1 and Pressure PED 97/23/CE standards for quality assurance. Knife edge black aluminium pointer improves measurement precision. IP32 rated protection against ingress of solid objects. Cupreous metal Bourdon tube for reliable pressure indication.

This Bourdon pressure gauge is ideal for use in industrial, manufacturing, pneumatic, hydraulic, and water treatment applications. It is a dependable instrument for pressure detection and control in compressed gas systems and water distribution networks.

Explore EnvMart’s extensive range of measuring instruments to find complementary gauges and tools for your industrial instrumentation needs.

Explore more products in our Pressure Gauges category.
