RS PRO Square Sleeve Bearing Axial Fan 40 mm x 40 mm x 10 mm 12V DC 1.2W 100mA 11.4 m³/h 6000 RPM 668-8808

Free Delivery in India | Lowest Global Shipping Charges

RS PRO Square Sleeve Bearing Axial Fan 40 mm x 40 mm x 10 mm 12V DC 1.2W 100mA 11.4 m³/h 6000 RPM 668-8808

Name: RS PRO Square Sleeve Bearing Axial Fan 40 mm x 40 mm x 10 mm 12V DC 1.2W 100mA 11.4 m³/h 6000 RPM 668-8808
Brand: RS PRO
SKU: 205357
Price: 6.96 USD
Availability: InStock



Category Axial Fan Brand RS PRO Condition New

Specifications

Country of Origin	India
Power Consumption	1.2W
Brand	RS PRO
Height	40mm
Fan Speed	6000rpm
Air Flow	11.4m³/h
Model	668-8808
Depth	10mm
Noise Level	25dB
Width	40mm
Series	RS PRO
Maximum Current	100mA
Terminal type	Wire
External Depth	10.5mm
Supply Voltage	12V dc
Bearing Type	Sleeve
Standards/Approvals	UL, TUV, RoHS, CE
Fan Frame Size	40 mm
Fan Frame Type	Square
Direction of Curve	Backward
Sunon Axial Fan, 12V dc, 8.2 cfm, 1.14 W, 95 mA Max 40 mm 40mm 10 mmBrand	Sunon

Key Features

The axial fan features a square frame measuring 40 mm by 40 mm by 10 mm.
It operates with a sleeve bearing type for reliable and cost-effective performance.
The fan speed reaches up to 6000 RPM, ensuring effective air movement.
The product consumes a maximum current of 100 mA at 12 volts DC.
The noise output is low at 25 dB, making it suitable for noise-sensitive environments.
The fan is constructed with black materials and has backward curve blades.
Sealed sleeve technology retains bearing lubricant, increasing fan lifespan.
It is suitable for cooling electronic components, server racks, electrical cabinets, and production machinery.

Product Description

RS PRO 668-8808 is a compact and efficient square frame axial fan designed for various industrial and electrical cooling applications. Operating at 12V DC with a power consumption of 1.2W, this fan delivers an air flow rate of 11.4 m³/h while maintaining a quiet noise level of 25 dB.

The fan frame dimensions measure 40 mm in height, 40 mm in width, and 10 mm in depth, making it ideal for installation in tight spaces such as electrical cabinets and enclosures. It features a sleeve bearing type with sealed sleeve technology that enhances lubricant retention, providing longer operating life compared to standard sleeve bearings.

With a maximum current draw of 100 mA and a fan speed of up to 6000 RPM, this fan efficiently cools critical components by pushing air through the system using its backward curved blades. The black construction complements industrial settings and ensures durability.

This RS PRO axial fan is widely used in applications including server racks to cool networking equipment, electrical enclosures to protect sensitive electronics, and production line machinery to prolong motor and gearbox life. Its certifications - UL, TUV, RoHS, and CE - confirm adherence to international safety and environmental standards.

The axial fan has a square 40 mm x 40 mm x 10 mm frame size for compact installations. It uses a sleeve bearing with sealed sleeve technology for extended durability. Operates at 12V DC with a power consumption of 1.2W and current of 100mA max.

Produces an airflow of 11.4 cubic meters per hour at 6000 RPM speed. Generates low noise level of 25 dB suitable for quiet environments. The fan blades have a backward curved design for efficient airflow. Black construction ensures resistance and blend with industrial equipment.

Applications include electronics cooling, server racks, electrical cabinets, and manufacturing. Complies with UL, TUV, RoHS, and CE standards for quality and safety. Explore the RS PRO range of Axial Fans at EnvMart for reliable thermal management solutions for industrial and commercial use.
