Amphenol Industrial signalmate C091 12 Pole Straight M16 DIN Socket Panel Mount 3A 150V IP40 T3638 100 RS

Name: Amphenol Industrial signalmate C091 12 Pole Straight M16 DIN Socket Panel Mount 3A 150V IP40 T3638 100 RS
Brand: Amphenol Industrial
SKU: 198564



Category Circular Connectors Brand Amphenol Industrial Condition New

Specifications

Country of Origin	China
Voltage	150V
Brand	Amphenol Industrial
Orientation	Straight
Current	3A
Model	T3638 100 RS
IP Rating	IP40
Mount Type	Panel Mount
Housing Material	Polymer, Metal
Contact Material	Brass
Series	signalmate C091
Termination Type	Solder
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-40°C
Pole Format	12
Contact Plating	Silver
Number of Contacts	12
Contact Gender	Female
Mating Type	Screw-On
Connector Size	M16

Key Features

This panel mount socket features a robust metal screw thread and locking ring ensuring secure and reliable connections.
The connector is rated IP40 for protection against solid objects and has solder-type terminations.
It incorporates silver plated brass female contacts for excellent conductivity and durability.
The product operates in a temperature range from -40°C to 85°C, suitable for diverse industrial environments.
The housing is composed of durable polymer and metal materials, combining strength with lightweight design.
The straight orientation and screw-on mating type facilitate easy installation and maintenance.
Silver plating on contact surfaces enhances corrosion resistance and signal integrity.
Internal metal strain relief ensures cable stability and extends connector lifespan.

Product Description

Amphenol Industrial's T3638 100 RS signalmate C091 DIN socket is a high-quality 12 pole straight connector featuring a panel mount configuration. It supports a current rating of 3A and voltage up to 150V, designed for robust industrial electronic applications.

This product incorporates a metal screw thread and locking ring mechanism that guarantees a secure and stable connection suitable for demanding environments. Its IP40 rating offers protection against solid foreign objects ensuring reliability in typical industrial settings.

The housing uses a combination of polymer and metal materials to deliver mechanical strength while maintaining lightweight characteristics. The female contacts are made of brass with silver plating to enhance electrical performance and corrosion resistance.

Terminations are solder type, optimized for permanent installations requiring stable electrical contacts. Operating temperature ranges between -40°C and 85°C, making it versatile for various industrial, manufacturing, and automation applications.

The connector features a straight orientation with screw-on mating type which facilitates ease of installation on panels with rear mounting and ring nut securing. This product has 12 contacts specialized for signal transmission.

It complies with DIN EN 60130-9 and IEC 60130-9 standards for metal coupling and locking rings. Silver-plated contacts assure low contact resistance and long-term durability. Internal metal strain relief protects cables from mechanical stress.

The connector is UL registered under file number E 63 093 ensuring recognized safety standards.

Ideal for industrial electronics, machinery controls, instrumentation, automation, and various manufacturing uses, this Amphenol Industrial DIN socket is engineered to provide reliable performance and longevity.
