Essentra PCB Card Guide Vertical Mount 114.3 mm Length, 1.6 mm Max PCB Thickness RSDC-450

Essentra RSDC-450 PCB Card Guide Vertical Mount is engineered for reliable vertical positioning of printed circuit boards up to a maximum thickness of 1.6 mm and length of 114.3 mm. Constructed using high-performance Polyamide 66 material, this component offers excellent mechanical strength, chemical resistance, and durability required for demanding electronic applications.

This PCB card guide is ideal for industrial electronics assembly where secure and precise PCB retention is critical. Its vertical mount design facilitates easy integration into electronic equipment, aiding in rapid production and maintenance cycles. The guide supports PCBs ranging in thickness from 1.2 mm to 2.2 mm, making it a versatile choice for a wide spectrum of board layouts.

Essentra’s RSDC series adheres to RoHS standards, assuring compliance with restricted hazardous substances regulations to promote safer electronic products and environmentally friendly disposal. Manufactured in the United States, it meets stringent quality and performance criteria demanded by industrial, laboratory, manufacturing, and commercial electronic systems sectors.

The dimensions of 114.3 mm length and maximum PCB thickness of 1.6 mm balance physical strength with compact size, supporting efficient space utilization on equipment racks and PCB mounting plates. Polyamide 66 construction enhances long-term stability against wear, mechanical shocks, and environmental factors such as moisture and temperature variations.

Typical use cases include PCB handling systems, electronic assembly lines, test fixture configurations, and equipment maintenance where modular PCB replacement and firm retention are required. The vertical card guide simplifies design and assembly processes while maintaining board alignment and protection.

Constructed from durable Polyamide 66 ensuring robust performance. Supports maximum PCB thickness of 1.6 mm for versatility in PCB dimensions. Length of 114.3 mm provides optimal fit for various PCB assemblies. Vertical mount design facilitates secure and efficient PCB positioning.

RoHS compliant, ensuring environmentally safe manufacturing standards. Manufactured in the United States guaranteeing high quality and reliability.

Explore the range of PCB Card Guides and retainers at EnvMart for reliable and compliant PCB mounting solutions optimized for industrial and commercial electronic manufacturing and servicing.
