Entrelec SNA Series DIN Rail Terminal Block Blue, 4mm², 1-Level, Screw, 800V AC, 32A 1SNA125468R2200

Name: Entrelec SNA Series DIN Rail Terminal Block Blue, 4mm², 1-Level, Screw, 800V AC, 32A 1SNA125468R2200
Brand: Entrelec
SKU: 188300



Category DIN Rail Terminal Block Brand Entrelec Condition New

Specifications

Country of Origin	India
Voltage	800V ac
Brand	Entrelec
Colour	Blue
Model	1SNA125468R2200
Series	SNA
Termination Type	Screw
Maximum Operating Temperature	40°C
Number of Levels	1
Minimum Operating Temperature	-5°C
Pitch	6mm
Standards/Approvals	EU Directive 2002/95/EC, EAC, cUL, CSA, CE
Minimum Wire Size AWG	22AWG
Maximum Wire Size AWG	10AWG
Cable CSA	4mm²
Terminal Block Current	32A

Key Features

Moulded in tough flame-resistant polyamide 6.6 for durability and safety.
Suitable for operating temperatures from -5°C to 40°C.
Pitch of 6mm ensures compact and efficient wiring layout.
Compatible with wire sizes from 22 AWG to 10 AWG.
Captive terminal screws with hardened heads prevent burring and ensure secure connections.
Can be mounted on both asymmetric rail 'G' profile and Top hat profile.
Complies with EU Directive 2002/95/EC, EAC, cUL, CSA, and CE standards for quality and safety.
Colour-coded blue for easy identification in complex assemblies.

Product Description

Entrelec 1SNA125468R2200 SNA Series DIN Rail Terminal Block is a robust and reliable component designed for industrial and electrical power distribution installations. This terminal block features a blue flame-resistant polyamide 6.6 housing, suitable for use in environments with operating temperatures ranging from -5°C to 40°C.

The terminal block supports a wire cross-sectional area of up to 4mm², and accommodates wire sizes from 22 AWG to 10 AWG, ensuring compatibility with a broad range of wiring configurations. With a 1-level design and screw termination type, it offers secure cable connections essential for maintaining electrical integrity and safety.

It is rated for operation at up to 800V AC and a current carrying capacity of 32A, making it suitable for various industrial, manufacturing, and HVAC electrical systems. The 6mm pitch ensures optimized space utilization in panel assemblies.

The product is constructed for mounting on asymmetric rail 'G' profiles and standard top hat rails, offering flexible installation options. Terminal screws have hardened heads to prevent damage during installation, and the cable entry and clamp design facilitates easy installation with higher voltage and cable carrying capacity.

This terminal block complies with multiple certifications and standards, including EU Directive 2002/95/EC, EAC, cUL, CSA, and CE, guaranteeing adherence to rigorous safety and environmental norms. The blue colour coding aids in quick identification within electrical cabinets and assemblies.

Moulded in durable flame-resistant polyamide 6.6 material. Supports wire sizes from 22 AWG to 10 AWG with 4mm² cable cross-section. Operating voltage rating of 800V AC and current rating of 32A. Captive, hardened head terminal screws for secure connections.

Designed for DIN rail mounting on asymmetric 'G' and top hat profiles. Operating temperature range from -5°C to 40°C. Compliant with EU Directive 2002/95/EC, EAC, cUL, CSA, and CE standards. Blue colour for easy identification in assemblies.

6mm pitch suitable for compact installations.

This terminal block is ideal for industrial electronics, power distribution, manufacturing control panels, and HVAC electrical wiring tasks. Its robust build quality and compliance with safety standards ensure reliable and safe electrical connections in these environments.
