WEG CWC Series Contactor Motor Control 110V AC Coil, 3-Pole, 12 A, 5.5 kW, 690V AC CWC012-10-30D13

Free Delivery in India | Lowest Global Shipping Charges

WEG CWC Series Contactor Motor Control 110V AC Coil, 3-Pole, 12 A, 5.5 kW, 690V AC CWC012-10-30D13



Category Contactors Brand WEG Condition New

Specifications

Country of Origin	Brazil
Brand	WEG
Function	Motor Control
Length	58mm
Model	CWC012-10-30D13
Depth	52mm
Width	45mm
Mount Type	DIN Rail
Series	CWC
Power Rating	5.5kW
Maximum Operating Temperature	55°C
Minimum Operating Temperature	-25°C
Terminal type	Screw
Number of Poles	3
Standards/Approvals	IEC, RoHS, UL
Contact Voltage	690V ac
Coil Voltage	110V ac
Normal State Configuration	3 NO
Contact Current	12A
Number of Auxiliary Contacts	1
Auxiliary Contact Configuration	1 NO
Operational Current Ie	12A
Control Circuit Voltage Uc	110V ac
Contactor Application	Motor Control
Pole and Throw Configuration	3PST

Key Features

Coil voltage is 110V AC for reliable electromagnet operation.
Designed with 3 poles and 3 normally open (3 NO) contacts for effective motor switching.
Contact current rating is 12 A with power rating of 5.5 kW at 690V AC.
Mounts easily on DIN rails with screw terminals for secure connection.
Wide operating temperature range from -25°C to 55°C ensures durability.
Includes 1 auxiliary contact configured as 1 NO for additional control functions.
Compact dimensions with 58 mm length, 45 mm width, and 52 mm depth save installation space.
Designed and tested according to IEC, RoHS, and UL standards for safety and performance.

Product Description

The WEG CWC012-10-30D13 Contactor belongs to the CWC series, which offers a compact yet robust solution tailored for motor control applications in industrial and automation sectors. This contactor operates with a 110V AC coil voltage and features a 3-pole configuration with 12 A contact current capacity, delivering 5.5 kW power rating at 690V AC. Its compact design allows easy DIN rail mounting, facilitating quick and secure installation in control panels.

Designed to meet stringent IEC, RoHS, and UL standards, this contactor ensures reliable operation across a broad temperature range of -25°C to +55°C. It includes one auxiliary contact configured as normally open (1 NO) to provide additional switching options within control circuits. Its screw terminal design guarantees durable and safe electrical connections.

This WEG contactor is suitable for numerous industrial automation use cases including motor starters, control circuits, and machinery requiring reliable switching components. Its compact size and modular design are ideal for space-saving installations while maintaining high switching performance and durability.

110V AC coil voltage ensures consistent electromagnet activation. 3 poles with 3 normally open contacts provide effective power switching. 12 A contact current rating with 5.5 kW power capacity supports medium power motors.

DIN rail mounting and screw terminals enable straightforward installation. Operates reliably between -25°C and 55°C temperature range. Single auxiliary contact (1 NO) for auxiliary control functions. Compact dimensions: 58 mm (L) × 45 mm (W) × 52 mm (D) for efficient panel space use.

Complies with IEC, RoHS, and UL standards for quality and safety. Ideal for automation, manufacturing, and motor control industrial applications. Explore our broad range of WEG Contactors in EnvMart's Automation & Control Gear category for advanced control solutions tailored to your industrial needs.
