WEG CWC Series Motor Control Contactor, 110V AC Coil, 3-Pole, 7 A, 3 kW, 3 NO Contacts, 690V AC CWC07-01-30D13

Free Delivery in India | Lowest Global Shipping Charges

WEG CWC Series Motor Control Contactor, 110V AC Coil, 3-Pole, 7 A, 3 kW, 3 NO Contacts, 690V AC CWC07-01-30D13



Category Contactors Brand WEG Condition New

Specifications

Country of Origin	Brazil
Brand	WEG
Function	Motor Control
Length	58mm
Model	CWC07-01-30D13
Depth	52mm
Width	45mm
Mount Type	DIN Rail
Series	CWC
Power Rating	3kW
Maximum Operating Temperature	55°C
Minimum Operating Temperature	-25°C
Terminal type	Screw
Number of Poles	3
Standards/Approvals	RoHS, UL, IEC
Contact Voltage	690V ac
Coil Voltage	110V ac
Normal State Configuration	3 NO
Contact Current	7A
Number of Auxiliary Contacts	1
Auxiliary Contact Configuration	1 NC
Operational Current Ie	7A
Control Circuit Voltage Uc	110V ac
Contactor Application	Motor Control
Pole and Throw Configuration	3PST

Key Features

The contactor is designed for motor control applications and includes 3 normally open contacts.
It has a compact and modular design suitable for DIN rail mounting.
Equipped with 1 auxiliary contact configured as normally closed for control circuit flexibility.
Screw type terminals ensure secure and reliable electrical connections.
Built to operate reliably in temperatures ranging from -25°C to +55°C.
Constructed in compliance with IEC/EN60947 and DIN VDE 0660 standards for robustness and safety.
Manufactured in Brazil with a professional range assuring high quality and performance.
Designed for easy and direct mounting on DIN rails or panels with built-in auxiliary contacts.

Product Description

The WEG CWC07-01-30D13 is a motor control contactor from the professional CWC Series, designed to reliably switch electric motors. Featuring a 110V AC coil and 3 poles rated at 7 A, it supports motor loads up to 3 kW at 690V AC. This contactor is built to meet IEC/EN60947 and DIN VDE 0660 standards, ensuring compliance and operational safety.

Its compact, modular design with dimensions 58 mm length, 45 mm width, and 52 mm depth allows efficient use of panel space. It can be mounted directly on DIN rails or panels using screw terminals for secure electrical connections. The device incorporates three normally open main contacts plus one normally closed auxiliary contact, providing flexible control options in automation systems.

Engineered for a wide operating temperature range from -25°C to +55°C, the contactor is suitable for diverse industrial environments including manufacturing, HVAC, and electrical automation. Its robust construction and compliance with global standards like RoHS, UL, and IEC ensure durability and safety in demanding applications.

With its reliable motor control functionality, compact footprint, and professional-grade build quality, the WEG CWC07-01-30D13 contactor is ideal for industrial automation engineers and electricians engaged in motor control and switching tasks. The product is made in Brazil and represents WEG's commitment to industrial-grade electrical components.

The contactor includes a 110V AC coil voltage and is suitable for 3-pole motor control switching. Rated for 7 A operational current and supports a power rating of 3 kW at 690V AC. Features 3 normally open main contacts and 1 normally closed auxiliary contact.

Compact dimensions with DIN rail and panel mounting options facilitate flexible installation. Compliance with IEC/EN60947, DIN VDE 0660, RoHS, and UL certifications ensure global standard adherence. Designed to operate reliably in temperatures from -25°C to +55°C for robust industrial use.

Manufactured in Brazil as part of the reliable WEG CWC professional contactor series. Explore more contactor options and automation components with EnvMart for your industrial and electrical project needs.
