TDK 1 nF Multilayer Ceramic Capacitor, 50V DC, ±10 % Tolerance, Surface Mount, 0402 Package, Model C1005X7R1H102K050BA

TDK C1005X7R1H102K050BA is a high-quality multilayer ceramic capacitor with 1 nF capacitance and ±10 % tolerance. It is rated for 50V DC voltage and fabricated with an X7R dielectric material that ensures stable performance in varied operating temperatures from -55°C to 125°C. This surface mount device comes in a 0402 package size measuring 1 mm length, 0.5 mm width, and 0.5 mm height, suitable for space-constrained electronic assemblies.

The capacitor construction uses stacked multilayers of ceramic dielectrics and conductive inner electrodes, offering a monolithic structure that affords excellent mechanical strength and electrical reliability. Its low ESR and ESL attributes enable outstanding frequency characteristics, reducing signal losses in power supply filtering, telecommunications, and general electronics equipment such as AV devices, computers, industrial robots, and mobile devices.

Termination is designed for solder mounting, supporting modern automated circuit board assembly. The device is packaged on tape and reel for streamlined mass production integration. Furthermore, compliance with RoHS and REACH directives ensures the capacitor meets environmental and safety standards required in industrial, commercial, and consumer electronics applications.

Typical use case scenarios include power supply circuits, signal filtering, noise suppression, and timing networks across a wide range of electronic and electrical equipment including home appliances, telecommunications, industrial machinery, and automotive electronics where stable capacitance and high reliability are crucial.

The capacitor uses X7R dielectric for temperature stability. The surface mount solder termination fits compact PCB layouts. Operating temperature range supports harsh environments. Tape & reel packaging facilitates automated assembly.

High mechanical strength due to monolithic construction. Low ESR and ESL improve frequency response performance. Non-polarized design allows flexible circuit integration.

This TDK multilayer ceramic capacitor is ideal for engineers and technicians requiring robust, high-performance passive components for demanding electronic designs. Explore EnvMart for a broad selection of high-quality multilayer ceramic capacitors from trusted brands.
