Siemens SINAMICS G115D Wall Mount AC Converter 380-480V, 6.2A High Level Output, 3.1A Low Level Output 6SL3520-2XD01-1AB0
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | Siemens |
| Height | 156mm |
| Length | 129mm |
| Model | 6SL3520-2XD01-1AB0 |
| Width | 380mm |
| Mount Type | Wall |
| Series | SINAMICS G115D |
| Input Type | AC |
| Maximum Operating Temperature | 55°C |
| Minimum Operating Temperature | 30°C |
| Standards/Approvals | EMC Directive 2014/30/EC, Low-Voltage Directive 2014/35/EC, REACH, RoHS, SEMI F47, UL, CE, C-Tick (RCM), cUL, EAC, KCC |
| Maximum Supply Voltage | 480V |
| Minimum Supply Voltage | 380V |
| Maximum High Level Output Current | 6.2A |
| Maximum Low Level Output Current | 3.1A |
Key Features
- Operates with input AC voltage between 380V and 480V.
- Maximum high level output current is 6.2 amps.
- Maximum low level output current is 3.1 amps.
- Designed for wall mounting to save space and reduce cooling needs.
- Operating temperature range from 30°C to 55°C ensures performance in demanding environments.
- Compact physical dimensions measuring 129mm length, 380mm width, and 156mm height.
- Complies with multiple international standards including EMC Directive and Low-Voltage Directive.
- Supports SINAMICS G115D series geared motors for enhanced motor control.
Product Description
Siemens 6SL3520-2XD01-1AB0 is a Wall Mount AC Converter from the SINAMICS G115D series designed for industrial power conversion needs. Operating with an input voltage range of 380 to 480 volts and supporting maximum output currents of 6.2A (high level) and 3.1A (low level), it ensures efficient and reliable power delivery. This converter supports SIMOGEAR 2KJ8 geared motors and is compatible with three-phase asynchronous motors with efficiency class IE3 or high-efficiency synchronous reluctance motors with efficiency class IE4.
It is optimized for horizontal conveyor system applications, capable of simple speed control to sophisticated encoderless vector control. The integrated safety features include Safe Torque Off (STO) with fail-safe digital inputs F-DI or PROFIsafe, enhancing operational safety in industrial environments. Its modular design enables user-friendly installation and commissioning without the need for control cabinets, reducing space requirements and cooling demands.
With a compact footprint (129 mm length, 380 mm width, and 156 mm height) and an operating temperature range of 30°C to 55°C, this converter adapts well to various industrial settings. The unit complies with important regulatory standards such as EMC Directive 2014/30/EC, Low-Voltage Directive 2014/35/EC, REACH, RoHS, UL, CE, cUL, EAC, KCC, and SEMI F47.
Manufactured in the United Kingdom, the Siemens 6SL3520-2XD01-1AB0 offers a robust, reliable, and versatile solution suitable for industrial, manufacturing, and conveyor automation tasks. Its wall mount design simplifies installation and maintenance while delivering high performance.
Operates with input AC voltage between 380V and 480V. Maximum high level output current is 6.2 amperes. Maximum low level output current is 3.1 amperes. Designed for wall mount installation. Compact dimensions: 129mm (L) x 380mm (W) x 156mm (H).
Meets extensive international EMC, safety, and environmental standards. Supports energy-efficient motor classes IE3 and IE4. Integrated safety with Safe Torque Off and PROFIsafe support. Modular design for easy installation without control cabinets.
Suitable for industrial conveyor system applications and motor control. Explore more converters and power solutions at EnvMart for industrial and manufacturing automation.
Explore more products in our AC Converters category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It operates with an input AC voltage range of 380V to 480V.
The maximum high level output current is 6.2A, and the maximum low level output current is 3.1A.
The unit has compact dimensions of 129mm in length, 380mm in width, and 156mm in height.
It operates effectively within a temperature range of 30°C to 55°C.
Yes, it supports SINAMICS G115D series geared motors for enhanced motor control.
It includes Safe Torque Off (STO) with fail-safe digital inputs F-DI or PROFIsafe, enhancing operational safety.
It complies with multiple international standards including the EMC Directive, Low-Voltage Directive, REACH, RoHS, UL, CE, and others.
It is compatible with three-phase asynchronous motors with efficiency class IE3 and high-efficiency synchronous reluctance motors with efficiency class IE4.
It is designed for wall mounting, which simplifies installation and reduces cooling needs.
It is optimized for horizontal conveyor system applications and capable of simple speed control to sophisticated encoderless vector control.
This model is manufactured in the United Kingdom.
The input type for this converter is AC.
