ABB Tmax XT Molded Case Circuit Breaker 3-Pole 1.6A Breaking Capacity 65 kA Fixed 1SDA067000R1 XT2N 160 TMD 1.6A FF
Specifications
| Country of Origin | Italy |
|---|---|
| Range | Tmax XT |
| Brand | ABB |
| Height | 130mm |
| Model | 1SDA067000R1 XT2N 160 TMD 1.6A FF |
| Depth | 82.5mm |
| Width | 90mm |
| Mount Type | Fixed |
| Current Rating | 1.6A |
| Series | Tmax XT |
| Terminal type | Fixed |
| Breaking Capacity | 65kA |
| Number of Poles | 3 |
| Standards/Approvals | IEC, CE, RoHS |
| Rated AC Voltage | 690V ac |
| Rated DC Voltage | 500V dc |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Lever |
| Rated current (In) | 1.6 A In |
| Rated frequency (f) | 50/60 Hz |
| Rated voltage (Ur) | 690 V |
| Rated impulse withstand voltage (Uimp) | 8 kV |
Key Features
- Rated AC voltage of 690V ensures suitability for high-power applications.
- Fixed mounting type with front terminals for straightforward installation.
- Thermal magnetic tripping mechanism for precise and reliable overload protection.
- Compact dimensions of 130mm height, 90mm width, and 82.5mm depth.
- Lever reset actuator provides easy manual operation.
- Compliant with IEC, CE, and RoHS standards ensuring safety and environmental compliance.
- Rated DC voltage of 500V and rated impulse withstand voltage of 8 kV for robust performance.
- Manufactured in Italy to ensure quality and reliability in industrial and commercial environments.
Product Description
ABB 1SDA067000R1 XT2N 160 TMD 1.6A FF Molded Case Circuit Breaker is a high-performance electrical protection device designed to safeguard electrical circuits in industrial, commercial, and manufacturing environments. It features a 3-pole configuration with a precise current rating of 1.6A and a breaking capacity of 65 kA, which ensures efficient interruption of short circuits or overload currents.
The breaker is designed for fixed mounting and incorporates front terminals, simplifying installation and maintenance. It operates with a thermal magnetic tripping mechanism, offering reliable protection against both overload and short circuit conditions. This product has a rated AC voltage of 690 volts and a rated DC voltage of 500 volts, making it versatile for various electrical systems.
The compact dimensions of 130mm height, 90mm width, and 82.5mm depth allow for space-efficient panel installations. Ease of use is enhanced by the lever-type reset actuator. Compliance with IEC, CE, and RoHS standards assures high safety, environmental responsibility, and quality manufacturing.
This circuit breaker is ideally suited for industrial automation, power distribution boards, HVAC systems, and general electrical control panels requiring high breaking capacity and precision protection. Manufactured in Italy, it reflects stringent quality control and durability.
Rated current: 1.6 A. Number of poles: 3. Breaking capacity: 65 kA. Mounting type: Fixed. Tripping mechanism: Thermal Magnetic. Reset actuator: Lever. Rated AC voltage: 690 V. Rated DC voltage: 500 V. Rated impulse withstand voltage: 8 kV.
Compliances: IEC, CE, RoHS.
Choose ABB Tmax XT Molded Case Circuit Breaker for reliable electrical protection in diverse industrial and commercial applications. Explore more circuit breakers and electrical components on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The breaking capacity of this molded case circuit breaker is 65 kA, which ensures effective interruption of short circuits or overload currents.
This model has a rated current of 1.6 A, making it suitable for specific electrical applications requiring this current rating.
The dimensions of this circuit breaker are 130mm in height, 90mm in width, and 82.5mm in depth, allowing for space-efficient installations.
It utilizes a thermal magnetic tripping mechanism, providing reliable protection against both overload and short circuit conditions.
The rated AC voltage for this model is 690V, ensuring its suitability for high-power applications.
Yes, it is compliant with IEC, CE, and RoHS standards, ensuring safety and environmental compliance.
This circuit breaker is designed for fixed mounting, with front terminals for straightforward installation.
The rated DC voltage for this model is 500V, making it versatile for various electrical systems.
The rated impulse withstand voltage for this circuit breaker is 8 kV, which contributes to its robust performance.
It features a lever reset actuator, which allows for easy manual operation.
This circuit breaker is part of the Tmax XT series, which is known for its high-performance electrical protection.
This model is manufactured in Italy, reflecting stringent quality control standards.
