ABB Formula DSA Molded Case Circuit Breaker 1-Pole 80A Breaking Capacity 25 kA Fixed 1SDA066693R1
Specifications
| Country of Origin | Italy |
|---|---|
| Range | Formula DSA |
| Brand | ABB |
| Height | 130mm |
| Model | 1SDA066693R1 |
| Depth | 60mm |
| Width | 25.4mm |
| Mount Type | Fixed |
| Current Rating | 80A |
| Series | 1SDA06 |
| Terminal type | Front |
| Breaking Capacity | 25kA |
| Number of Poles | 1 |
| Standards/Approvals | CE, IEC |
| Rated AC Voltage | 415V ac |
| Rated DC Voltage | 125V dc |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Lever |
Key Features
- Rated for 415 V AC and 125 V DC operational voltages.
- Features a thermal magnetic tripping mechanism for precise protection.
- Equipped with front terminals and a lever-type reset actuator.
- Compact dimensions with 130 mm height, 25.4 mm width, and 60 mm depth.
- Complies with CE and IEC standards for safety and performance.
- Manufactured in Italy ensuring high-quality build.
- Designed for fixed mounting in electrical distribution systems.
- Offers a 125 A rated uninterrupted current (Iu) capability.
Product Description
ABB 1SDA066693R1 Formula DSA molded case circuit breaker is engineered for industrial and commercial electrical protection applications. This 1-pole fixed mounting breaker has an 80 ampere current rating and a breaking capacity of 25 kiloamperes, suitable for safeguarding circuits against overloads and short circuits. It operates reliably at 415 volts AC and 125 volts DC, enabling versatile installation in various power distribution systems.
The breaker includes a thermal magnetic tripping mechanism ensuring fast response to thermal overloads and short circuits, which minimizes equipment damage and enhances safety. It also features a lever-type reset actuator and front terminal type for easy operation and wiring accessibility.
Compactly designed with height of 130 mm, width of 25.4 mm, and depth of 60 mm, it fits well within electrical panels without occupying excessive space. The device meets CE and IEC standards, demonstrating compliance with international safety and quality requirements. Its 125 ampere uninterrupted current rating and 6 kV impulse withstand voltage rating (Uimp) provide robustness in high-demand environments.
Manufactured in Italy, the ABB Formula DSA circuit breaker ensures durable construction and dependable performance. It is ideal for industrial, manufacturing, commercial, and electrical automation systems requiring high-reliability circuit protection.
Rated for 415 V AC and 125 V DC operational voltages. Thermal magnetic tripping mechanism for overload and short circuit protection. Front terminal connections with lever-type reset actuator. Compact size: 130 mm height, 25.4 mm width, 60 mm depth.
CE and IEC compliant for global safety standards. 125 A rated uninterrupted current (Iu) capacity. 6 kV impulse withstand voltage rating (Uimp). Fixed mounting type ensures secure installation. Manufactured in Italy with quality assurance.
This circuit breaker is a critical component in electrical distribution and automation systems, providing reliable protection and operational longevity. Explore more ABB Molded Case Circuit Breakers and related electrical protection products at EnvMart for comprehensive electrical system solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This molded case circuit breaker has a current rating of 80 amperes.
It features a breaking capacity of 25 kiloamperes (kA).
The circuit breaker is rated for 415 volts AC and 125 volts DC operational voltages.
It utilizes a thermal magnetic tripping mechanism for protection against overloads and short circuits.
The dimensions are 130 mm in height, 25.4 mm in width, and 60 mm in depth.
This model is designed for fixed mounting in electrical distribution systems.
It features a lever-type reset actuator for easy operation.
It complies with CE and IEC standards for safety and performance.
It is manufactured in Italy, ensuring quality construction.
The impulse withstand voltage rating (Uimp) is 6 kV.
It is equipped with front terminals for easy wiring accessibility.
This circuit breaker is suitable for industrial, manufacturing, commercial, and electrical automation systems.
