ABB Molded Case Circuit Breaker 3-Pole 63A 690V AC Breaking Capacity 85kA Fixed 1SDA067817R1 XT2S 160 Ekip LSIG 63A FF

ABB 1SDA067817R1 XT2S 160 Ekip LSIG 63A FF Molded Case Circuit Breaker is a 3-pole device engineered for electrical circuit protection in industrial, commercial, and manufacturing environments. Rated at 63 amperes with a high breaking capacity of 85 kA, this breaker ensures robust interruption of fault currents, safeguarding electrical equipment and personnel.

The breaker is designed with a fixed mounting type and front fixed terminals, enabling secure and reliable electrical connections in switchboards and control panels. The rated AC voltage is 690 V, supporting both 50 Hz and 60 Hz frequency systems typical in global electrical installations.

Incorporating a solid state tripping mechanism with Ekip LSIG technology, this breaker offers precise and adaptive protection responsive to overloads, short circuits, and earth faults. The lever reset actuator simplifies manual resetting, contributing to operational convenience and safety.

With a rated impulse withstand voltage of 8 kV, the breaker is capable of handling transient voltage spikes, enhancing durability and longevity. Its compact dimensions (130 mm height, 90 mm width, 82.5 mm depth) allow for integration into constrained electrical cabinet spaces.

Manufactured in Italy with compliance to CE, IEC, and RoHS standards, this product aligns with stringent quality, safety, and environmental regulations. It carries the ABB Better World designation, emphasizing sustainability through design for disassembly and reduced environmental impact.

This Molded Case Circuit Breaker is widely employed across electrical and automation systems, industrial power distribution, manufacturing plants, and HVAC systems, providing dependable circuit protection and operational efficiency.

This circuit breaker features a fixed mounting type for stable installation. Equipped with a solid state tripping mechanism for reliable protection. Includes a lever reset actuator for easy manual operation. The breaker supports rated current of 63 A and rated uninterrupted current of 160 A.

Implements front fixed terminals for safe and secure electrical connections. Rated AC voltage is 690 V with a rated frequency range of 50/60 Hz. Constructed to withstand an impulse voltage of 8 kV ensuring high durability.

Compact dimensions of 130 mm (H) x 90 mm (W) x 82.5 mm (D) facilitate space-saving installations. Manufactured in Italy adhering to CE, IEC, and RoHS standards ensuring compliance and safety. Designed for disassembly as part of the ABB Better World sustainability initiatives.
