ABB Molded Case Circuit Breaker Tmax XT 3-Pole 10A 690V AC Breaking Capacity 85 kA 1SDA067810R1 XT2S 160 Ekip LSI 10A FF
Specifications
| Country of Origin | Italy |
|---|---|
| Range | Tmax XT |
| Brand | ABB |
| Height | 130mm |
| Model | 1SDA067810R1 XT2S 160 Ekip LSI 10A FF |
| Depth | 82.5mm |
| Width | 90mm |
| Mount Type | Fixed |
| Current Rating | 10A |
| Series | 1SDA06 |
| Terminal type | Fixed |
| Breaking Capacity | 85kA |
| Number of Poles | 3 |
| Standards/Approvals | CE, IEC, RoHS |
| Rated AC Voltage | 690V ac |
| Better World Claim | Designed for Disassembly |
| Tripping Mechanism | Solid State |
| Reset Actuator Type | Lever |
| Rated current (In) | 10 A In |
| Rated frequency (f) | 50/60 Hz |
| Rated voltage (Ur) | 690 V |
| Rated impulse withstand voltage (Uimp) | 8 kV |
Key Features
- The circuit breaker is designed with a breaking capacity of 85 kA for high fault current interruption.
- It operates at a rated AC voltage of 690V, suitable for industrial applications.
- Incorporates a solid state tripping mechanism with Ekip LSI release for precise fault detection.
- Features a lever-type reset actuator for easy manual operation.
- Front fixed terminals ensure reliable and secure electrical connections.
- The device dimensions are 130mm height, 90mm width, and 82.5mm depth, allowing compact installation.
- Supports rated frequencies of 50/60 Hz and withstands impulse voltages up to 8 kV.
- Complies with CE, IEC, and RoHS standards ensuring quality and environmental compliance.
Product Description
ABB 1SDA067810R1 XT2S 160 Ekip LSI 10A FF Molded Case Circuit Breaker is a high-performance protection device designed for industrial and commercial electrical systems. Operating at 690V AC and rated for 10A current, it provides reliable circuit interruption with a breaking capacity of 85 kA to safeguard against overloads and short circuits.
Equipped with a solid state tripping mechanism under the Ekip LSI series, this MCCB enhances fault detection precision and operational safety. The fixed mounting type and front fixed terminals ensure stable installation and secure wiring connections, facilitating maintenance and installation.
The breaker features a lever reset actuator for simple manual resetting after trip events. Compact dimensions of 130mm height, 90mm width, and 82.5mm depth support flexible panel mounting without demanding large space.
Designed to meet CE, IEC, and RoHS certifications, it aligns with stringent European and international safety and environmental standards. Suitable for various industrial applications, including automation, manufacturing, and electrical distribution systems, this device is manufactured in Italy to ABB’s quality standards.
Key technical parameters include rated current 10A, rated frequency 50/60 Hz, and rated impulse withstand voltage up to 8 kV, ensuring robust performance under electrical stress conditions.
The circuit breaker’s 3-pole configuration supports three-phase power protection. Its solid state tripping mechanism increases lifespan and reliability compared to thermal-magnetic options. The device is part of ABB’s Better World product line, designed for sustainability and disassembly.
It is ideal for industrial control panels, motor protection, and HVAC system safeguarding. This product is a vital component in maintaining safety and continuity in demanding electrical systems.
For users seeking reliable Molded Case Circuit Breakers with advanced trip technology and robust construction, the ABB Tmax XT series offers trusted performance. Explore more ABB electrical protection solutions and related products at EnvMart, your industrial equipment sourcing partner.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The breaking capacity of this molded case circuit breaker is 85 kA, allowing it to interrupt high fault currents effectively.
This model operates at a rated AC voltage of 690V, making it suitable for various industrial applications.
It features a 3-pole configuration, which supports three-phase power protection.
The current rating for this circuit breaker is 10A, designed to handle electrical loads effectively.
This unit is equipped with a solid state tripping mechanism, which enhances fault detection precision and operational safety.
The dimensions are 130mm in height, 90mm in width, and 82.5mm in depth, allowing for compact installation.
It complies with CE, IEC, and RoHS standards, ensuring quality and environmental compliance.
This circuit breaker supports rated frequencies of 50/60 Hz, suitable for various electrical systems.
It features a lever-type reset actuator, allowing for easy manual operation after a trip event.
This model is manufactured in Italy, adhering to ABB's quality standards.
It is suitable for various industrial applications, including automation, manufacturing, and electrical distribution systems.
The rated impulse withstand voltage for this circuit breaker is 8 kV, ensuring robust performance under electrical stress conditions.
