ABB Tmax XT Molded Case Circuit Breaker 3-Pole 12.5A Breaking Capacity 200 kA Fixed 1SDA067681R1 XT2V 160 TMD 12.5A FF
Specifications
| Country of Origin | Italy |
|---|---|
| Range | Tmax XT |
| Brand | ABB |
| Height | 130mm |
| Model | 1SDA067681R1 XT2V 160 TMD 12.5A FF |
| Depth | 82.5mm |
| Width | 90mm |
| Mount Type | Fixed |
| Current Rating | 12.5A |
| Series | Tmax XT |
| Terminal type | Fixed |
| Breaking Capacity | 200kA |
| Number of Poles | 3 |
| Standards/Approvals | CE, RoHS, IEC |
| Rated AC Voltage | 690V ac |
| Rated DC Voltage | 500V dc |
| Better World Claim | Designed for Disassembly |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Lever |
| Rated current (In) | 12.5 A In |
| Rated frequency (f) | 50/60 Hz |
| Rated voltage (Ur) | 690 V |
| Rated impulse withstand voltage (Uimp) | 8 kV |
Key Features
- Equipped with a thermal magnetic tripping mechanism for reliable protection.
- Rated current of 12.5A suitable for varied electrical applications.
- Supports rated AC voltage of 690V and DC voltage of 500V for versatile usage.
- Constructed for fixed mounting with a lever-type reset actuator.
- Compact design with dimensions 130mm height, 90mm width, and 82.5mm depth.
- Complies with CE, RoHS, and IEC standards ensuring safety and quality.
- Designed for disassembly as part of the Better World sustainability commitment.
- Originates from Italy, guaranteeing premium manufacturing standards.
Product Description
ABB 1SDA067681R1 XT2V 160 TMD 12.5A FF Molded Case Circuit Breaker is a high-performance electrical protection device featuring 3 poles and a fixed terminal design. Rated for 12.5 amps, this circuit breaker possesses a robust breaking capacity of 200 kA and supports operation at rated AC voltage of 690 volts and DC voltage up to 500 volts. It employs a thermal magnetic tripping mechanism, ensuring precise and reliable disconnection under fault conditions.
The device is designed with a lever-style reset actuator for straightforward manual operation and optimized for fixed mounting installation. Its compact form factor measures 130mm in height, 90mm in width, and 82.5mm in depth, facilitating use in various industrial and commercial electrical panels where space and reliability are critical.
Meeting stringent international standards including CE, RoHS, and IEC certifications, this circuit breaker promises compliance with global electrical safety and environmental regulations. Moreover, as part of ABB's Better World product line, it is engineered for sustainability through design for disassembly, minimizing environmental impact and encouraging recyclability.
The product is manufactured in Italy, underscoring ABB’s commitment to quality and robust engineering. Ideal for industrial, commercial, and electrical automation applications, this Molded Case Circuit Breaker safeguards electrical circuits against overloads and short circuits efficiently.
Equipped with thermal magnetic tripping for enhanced protection. Fixed mounting type suitable for secure installations. Compact dimensions enable integration in tight panel spaces. Designed for disassembly supporting sustainability goals.
Compliant with major international safety standards. High breaking capacity ensures protection against severe fault currents. Lever reset actuator aids ease of use and maintenance. Manufactured in Italy guaranteeing premium build quality.
Explore ABB’s range of circuit breakers and related products at EnvMart for reliable industrial electrical safety solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The breaking capacity of this molded case circuit breaker is 200 kA, which provides robust protection against fault currents.
This model has a rated current of 12.5A, making it suitable for various electrical applications.
It supports a rated AC voltage of 690V and a rated DC voltage of 500V, allowing for versatile usage in different electrical systems.
This circuit breaker features a lever-type reset actuator, enabling straightforward manual operation for resetting after a trip.
The dimensions of this unit are 130mm in height, 90mm in width, and 82.5mm in depth, facilitating installation in compact spaces.
It is designed for fixed mounting, ensuring secure installation in electrical panels.
This model complies with CE, RoHS, and IEC standards, ensuring it meets international safety and environmental regulations.
It employs a thermal magnetic tripping mechanism, which provides reliable disconnection under fault conditions.
This circuit breaker is manufactured in Italy, reflecting high manufacturing standards.
The rated frequency for this model is 50/60 Hz, making it suitable for various electrical systems worldwide.
The rated impulse withstand voltage is 8 kV, providing additional protection against voltage surges.
Yes, it is designed for disassembly as part of ABB's Better World sustainability commitment, promoting recyclability and reduced environmental impact.
