ABB XT2L Molded Case Circuit Breaker 4-Pole 125A 690V AC 500V DC Thermal Magnetic Tripping Lever

ABB XT2L Molded Case Circuit Breaker model 1SDA067668R1 XT2L 160 TMA 125A 3P+N FF is a fixed 4-pole power distribution circuit breaker designed for robust electrical protection in industrial and commercial applications. It operates with a rated AC voltage of 690V and DC voltage of 500V, offering reliable service in varied electrical environments.

This circuit breaker is engineered with a thermal magnetic tripping mechanism, providing superior protection against overload conditions and short circuits. The lever reset actuator facilitates simple manual resetting after fault clearance.

Its high breaking capacity of 150 kA ensures safety under extreme fault conditions, protecting equipment and personnel. The device features fixed mounting and front terminals to enable secure and straightforward installation in power distribution panels.

Compact physical dimensions (130mm height, 120mm width, and 82.5mm depth) make this device suitable for integration in standardized electrical enclosures. The circuit breaker complies with CE, IEC, and RoHS standards, underscoring its conformity to international safety, quality, and environmental requirements.

Its design includes a neutral rated at 50% of the phases and a short circuit performance level L, offering balanced electrical protection. The rated uninterrupted current capability of 160 A allows it to sustain continuous operational loads reliably.

Manufactured in Italy, this ABB XT2L series unit embodies quality craftsmanship and advanced technology embedded in its construction. It is ideal for industrial, manufacturing, commercial, and electrical distribution systems requiring dependable circuit interruption components.

Fixed mounting with front terminals for stable installation. 150 kA breaking capacity for high fault current interruption. Thermal magnetic tripping mechanism for overload and short circuit protection. 4-pole design including neutral protection.

Complies with CE, IEC, and RoHS standards. Rated for 690V AC and 500V DC electrical applications. Compact dimensions: 130mm height, 120mm width, 82.5mm depth. Lever reset actuator for easy manual operation. Short circuit performance level L, neutral at 50% phases.

Manufactured in Italy for quality assurance.
