ABB Molded Case Circuit Breaker 4-Pole 100A Breaking Capacity 100 kA Fixed XT4H

Free Delivery in India | Lowest Global Shipping Charges

ABB Molded Case Circuit Breaker 4-Pole 100A Breaking Capacity 100 kA Fixed XT4H



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	XT4H
Brand	ABB
Height	160mm
Model	XT4H
Depth	82.5mm
Width	140mm
Mount Type	Fixed
Current Rating	100A
Series	1SDA06
Terminal type	Fixed
Breaking Capacity	100kA
Number of Poles	4
Standards/Approvals	IEC, RoHS, CE
Rated AC Voltage	690V ac
Better World Claim	Designed for Disassembly
Tripping Mechanism	Solid State
Reset Actuator Type	Lever
Short circuit performance level	H

Key Features

Rated current of 100A suitable for industrial power installations.
Breaking capacity of 100 kA ensures safety during short circuits.
Fixed mounting and terminal type for stable installation.
Complies with IEC, RoHS, and CE standards.
Compact dimensions with 140mm width, 160mm height, and 82.5mm depth.
Features solid state tripping mechanism with EL100 type release.
Rated operational voltage of 690V AC with 1000V insulation voltage.
Designed for easy disassembly supporting sustainability efforts.

Product Description

ABB XT4H model is a 4-pole molded case circuit breaker offering a nominal current rating of 100A with a breaking capacity of 100 kA. It features a fixed mounting type with front terminals designed for industrial electrical protection in commercial and manufacturing settings.

This circuit breaker supports a rated operational AC voltage of 690V and an insulation voltage (Ui) of 1000V to ensure robust performance under varying electrical loads. The device utilizes a solid state tripping mechanism identified as EL100 AC Ekip LS/I for precise and reliable tripping under short circuit conditions, classified under short circuit performance level H.

Physically, it has compact dimensions measuring 140mm in width, 160mm in height, and 82.5mm in depth, making installation convenient even in space-constrained electrical panels. The reset actuator is a lever type for simple manual operation.

Designed with sustainability in mind, this ABB circuit breaker is part of the Better World product line, promoting ease of disassembly and environmental responsibility. It holds certifications including IEC, RoHS, and CE standards, reflecting compliance with international safety and environmental regulations.

Manufactured in Italy, this product is suitable for use in diverse industrial, commercial, and automation applications requiring reliable overcurrent and short-circuit protection for electrical circuits.

Rated current of 100A suited for heavy-duty circuit protection. 100 kA breaking capacity for high fault tolerance. Solid state release mechanism for precise tripping. Fixed mounting and terminal for stable connections. Compact and standardized dimensions for easy panel integration.

Better World design for sustainability and disassembly. Certified to IEC, RoHS, and CE standards for safety and environmental compliance. Lever type reset actuator for user convenience. For reliable protection and compliance, explore the ABB catalog in EnvMart under Molded Case Circuit Breakers and related electrical components.
