ABB Tmax XT Molded Case Circuit Breaker 4-Pole 40A 690V AC Breaking Capacity 100kA 1SDA068531R1 XT4H 160 Ekip LS/I 40A FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Tmax XT Molded Case Circuit Breaker 4-Pole 40A 690V AC Breaking Capacity 100kA 1SDA068531R1 XT4H 160 Ekip LS/I 40A FF



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	160mm
Model	1SDA068531R1 XT4H 160 Ekip LS/I 40A FF
Depth	82.5mm
Width	140mm
Mount Type	Fixed
Current Rating	40A
Series	1SDA06
Terminal type	Fixed
Breaking Capacity	100kA
Number of Poles	4
Standards/Approvals	RoHS, IEC, CE
Rated AC Voltage	690V ac
Better World Claim	Designed for Disassembly
Tripping Mechanism	Solid State
Reset Actuator Type	Lever
Rated current (In)	40 A In
Rated frequency (f)	50/60 Hz
Rated voltage (Ur)	690 V
Rated impulse withstand voltage (Uimp)	8 kV

Key Features

Features a fixed mounting and front terminal design for secure installation.
Operates at a rated voltage of 690V AC and frequency of 50/60 Hz.
Utilizes a solid state tripping mechanism with a lever reset actuator.
Complies with RoHS, IEC, and CE standards ensuring safety and environmental compliance.
Designed for disassembly as part of the ABB Better World sustainability initiative.
Manufactured in Italy with high-quality construction and engineering.
Rated impulse withstand voltage is 8 kV to handle high transient conditions.

Product Description

The ABB 1SDA068531R1 XT4H 160 Ekip LS/I Molded Case Circuit Breaker is a high-performance 4-pole MCCB designed for industrial and commercial electrical distribution protection. It is rated at a current of 40 amperes and a breaking capacity of 100 kiloamperes, suitable for demanding applications requiring reliable interruption of short circuit currents.

This model features a fixed mounting type and front terminal connections, allowing straightforward installation in panels. The solid state tripping mechanism ensures precise and reliable operation, controlled via a lever reset actuator for ease of use.

Rated for 690 volts AC and operating frequencies of 50 to 60 Hz, this circuit breaker provides robust insulation with an 8 kV impulse withstand voltage rating. Its compact dimensions - 160 mm height, 140 mm width, and 82.5 mm depth - enable efficient space utilization in switchboards.

It is part of ABB's Better World program and is designed for disassembly to promote sustainability objectives.

This MCCB is ideal for use in electrical automation, manufacturing plants, commercial buildings, and other industrial environments where dependable overcurrent protection is essential. Its solid state release and robust build assure operational longevity and safety.

Fixed mounting with front terminals for secure connections. Solid state tripping for accurate fault detection. Complies with RoHS, IEC, and CE certifications. Designed for easy disassembly under ABB Better World program.

Compact size allows flexible panel integration. High breaking capacity of 100 kA ensures safety in fault conditions. Manufactured in Italy with superior quality standards. Rated impulse withstand voltage of 8 kV for transient protection.
