ABB Molded Case Circuit Breaker XT4H 3-Pole 63A Fixed Ekip I Solid State Release 690V AC 100kA Italy XT4H

Free Delivery in India | Lowest Global Shipping Charges

ABB Molded Case Circuit Breaker XT4H 3-Pole 63A Fixed Ekip I Solid State Release 690V AC 100kA Italy XT4H



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	XT4H
Brand	ABB
Height	160mm
Model	XT4H
Depth	82.5mm
Width	105mm
Mount Type	Fixed
Current Rating	63A
Series	1SDA06
Terminal type	Fixed
Breaking Capacity	100kA
Number of Poles	3
Standards/Approvals	CE, IEC, RoHS
Rated AC Voltage	690V ac
Better World Claim	Designed for Disassembly
Tripping Mechanism	Solid State
Reset Actuator Type	Lever
Short circuit performance level	H

Key Features

Rated current of 63 amperes with a breaking capacity of 100 kiloamperes.
Features a solid state tripping mechanism with Ekip I release type for precise protection.
Designed for a rated AC voltage of 690 volts and insulation voltage of 1000 V.
Compact dimensions measuring 160mm height, 105mm width and 82.5mm depth.
Equipped with front fixed terminals and lever reset actuator.
Complies with IEC, CE, and RoHS standards for safety and environmental compatibility.
Manufactured in Italy ensuring quality and reliability.
Suitable for fixed industrial and commercial switchgear applications.

Product Description

ABB XT4H Molded Case Circuit Breaker model series 1SDA06 offers a reliable solution for industrial and commercial electrical circuit protection. It features a fixed mounting type with 3 poles suitable for use in three-phase electrical systems. The breaker is rated for 63 amperes current capacity and operates at a rated AC voltage of 690 volts with an insulation voltage of 1000 volts, ensuring strong performance under demanding conditions.

This model includes a solid state tripping mechanism identified as Ekip I, providing rapid and accurate circuit interruption. The breaker has a high breaking capacity of 100 kA which allows it to safely interrupt fault currents of significant magnitude, protecting downstream electrical components and wiring.

The design includes front fixed terminals and a lever type reset actuator for ease of operation and maintenance. Its compact size (160mm height, 105mm width, and 82.5mm depth) facilitates integration into existing switchgear assemblies.

Compliant with industry standards including IEC, CE, and RoHS, this circuit breaker meets stringent safety and environmental guidelines. It also carries the ABB Better World designation, highlighting its design focus on sustainability and disassembly for recycling.

Manufactured in Italy, the ABB XT4H circuit breaker is engineered for long-term durability and performance in industrial automation, electrical infrastructure, HVAC systems, manufacturing plants, and commercial installations.

Rated 63A current rating with 100kA breaking capacity. Solid state Ekip I tripping mechanism ensures precise operation. Fixed mount type with front terminals for secure connections. Dimensions 160 mm (H) × 105 mm (W) × 82.5 mm (D) optimize panel space.

Conforms to IEC, CE, and RoHS certifications. Designed for easy reset with lever actuator type. Better World product designed for sustainability and disassembly. Ideal for industrial and commercial electrical protection applications.

This ABB Molded Case Circuit Breaker is part of the trusted XT4H range, widely used in electrical automation and protection systems. For more high-quality circuit breakers and related products, browse the appropriate categories on EnvMart.
