ABB Tmax XT Molded Case Circuit Breaker 4-Pole 125A Breaking Capacity 85 kA Fixed 1SDA068275R1 XT3S 250 TMG 125A FF

ABB 1SDA068275R1 XT3S 250 TMG 125A FF Molded Case Circuit Breaker 4-Pole 125A is designed for reliable protection and control in electrical distribution systems. It is engineered to provide high breaking capacity and robust performance in industrial, commercial, and institutional electrical setups.

This circuit breaker features a thermal magnetic tripping mechanism (TMG type) that ensures accurate fault detection and protection against overloads and short circuits. The fixed mounting and fixed terminal design provide secure and stable connections, facilitating easy installation and maintenance.

Rated for a current of 125 amperes, the breaker supports AC voltages up to 690V and DC voltages up to 500V, making it versatile for diverse applications including industrial automation, electrical panels, and power distribution networks.

The compact size, with dimensions of 150 mm in height, 140 mm in width, and 70 mm in depth, helps in optimizing panel space. Compliance with international standards such as IEC, CE, and RoHS ensures quality, safety, and environmental responsibility.

Other features include a lever-type reset actuator for user-friendly manual resetting and a rated impulse withstand voltage of 8 kV, which enhances dielectric strength against transient overvoltages.

Rated current of 125A with 4 poles for comprehensive circuit protection. Breaking capacity of 85 kA provides high fault tolerance. Fixed mounting and terminal type ensuring reliable installation. Thermal magnetic tripping mechanism for precise overcurrent protection.

Rated AC voltage of 690V and DC voltage of 500V for broad application range. Compact dimensions enable efficient panel integration. Compliant with IEC, CE, and RoHS standards. Lever reset actuator for ease of operation. Designed and manufactured in Italy, assuring high manufacture standards.

This ABB circuit breaker is ideal for use in industrial machines, manufacturing plants, commercial buildings, and electrical automation systems where safety and reliability are paramount. It supports sustainable practices as a 'Better World Product' with a claim of designed for disassembly, facilitating easier recycling and environmental responsibility.
