ABB Molded Case Circuit Breaker 4-Pole 250A 690V AC 500V DC Thermal Magnetic Tripping Mechanism XT4L

Free Delivery in India | Lowest Global Shipping Charges

ABB Molded Case Circuit Breaker 4-Pole 250A 690V AC 500V DC Thermal Magnetic Tripping Mechanism XT4L



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	XT4L
Brand	ABB
Height	160mm
Model	XT4L
Depth	82.5mm
Width	140mm
Mount Type	Fixed
Current Rating	250A
Series	XT4L
Terminal type	Fixed
Breaking Capacity	150kA
Number of Poles	4
Standards/Approvals	CE, IEC, RoHS
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Better World Claim	Designed for Disassembly
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Lever
Short circuit performance level	L

Key Features

Rated current capacity of 250A ensures robust power distribution.
Breaking capacity of 150 kA provides high short circuit performance.
Supports rated AC voltage of 690V and DC voltage of 500V.
Equipped with a lever type reset actuator for easy operation.
Compact dimensions with 160mm height, 140mm width, and 82.5mm depth.
Features fixed front terminals for secure installation.
Thermal magnetic tripping mechanism improves protection against faults.
Designed and manufactured in Italy with CE, IEC, RoHS compliance.

Product Description

ABB XT4L Molded Case Circuit Breaker 4-Pole 250A is engineered for reliable power distribution and protection in industrial and commercial electrical systems. Featuring a thermal magnetic tripping mechanism, it offers dependable short circuit and overload protection.

This fixed mounting breaker supports a rated AC voltage of 690V and a DC voltage rating of 500V, making it suitable for diverse power applications. The 150 kA breaking capacity ensures safe interruption of high fault currents, complying with IEC standards.

The breaker is designed with a lever-type reset actuator for straightforward manual operation and includes fixed front terminals to facilitate secure and stable electrical connections.

With compact dimensions of 160mm height, 140mm width, and 82.5mm depth, the XT4L breaker fits efficiently in control panels and switchgear assemblies.

Manufactured in Italy, this product is CE, IEC, and RoHS certified, embodying ABB's commitment to quality and sustainability. The thermal magnetic tripping mechanism allows adjustable instantaneous short circuit current settings ranging from 1250 to 2500 A, with a neutral at 50% of phases, providing customized protection levels.

Rated current capacity of 250A for power distribution needs. High breaking capacity of 150 kA for fault tolerance. Thermal magnetic tripping mechanism enhances protective capabilities. Fixed mounting and terminals for stable installation.

Conforms to CE, IEC, and RoHS standards. Compact size fits various switchgear applications. Designed for disassembly supporting sustainability initiatives. Lever-type reset actuator ensures easy manual control.

This Molded Case Circuit Breaker is ideal for industrial, commercial, manufacturing, and HVAC electrical protection applications where reliable interruption and safety are paramount. Browse the comprehensive range of ABB circuit breakers at EnvMart to find compatible power distribution solutions meeting your project's requirements.
